Allen-Bradley 150-F108NBD
The Allen-Bradley 150-F108NBD is a state-of-the-art SMC Flex Smart Motor Controller that can maximize industrial motors performance and efficiency. This solid-state soft-start controller incorporates powerful functionality and numerous protection features, making it indispensable for a wide range of demanding applications across sectors.
Technical Specifications:
The Allen-Bradley 150-F108NBD is compatible with a wide variety of power sources because of its wide control voltage range of 100 to 240V AC. Its four completely programmable auxiliary contacts can easily be adjusted to suit intricate control systems.
To further facilitate its incorporation into preexisting configurations, the controller has communication capabilities via two DPIs (Drive Peripheral Interfaces), one for linking to supplementary human interfaces and another for creating communication networks.
To meet the demands of demanding applications, this model can manage a maximum output current of 108 A and a maximum output power of 75 HP. All the necessary controls and monitoring functions are conveniently located on the front panel, and the built-in LCD screen with a backlight makes it easy to operate.
For locations where space is limited, the units 15 kg weight, 196.4 mm width, 212.2 mm depth, and 443.7 mm height make it an ideal choice. Under typical use, the 91 W steady-state heat dissipation rating shows that thermal energy is well managed.
Operating Modes:
The 150-F108NBD offers many working modes for better motor control and protection. Soft Start or Full Voltage Start reduces mechanical stress and electrical peaks at startup. Smart Motor Braking and Current Limit Start modes enhance motor acceleration and torque management for smooth operation. Due to Dual Ramp Start and Accu-Stop, the motor may be started and stopped with pinpoint accuracy.
Applications requiring a short boost or individualized start sequences can use the controllers Selectable Kickstart and Pump Start modes. Adjustable operating speeds and gradual deceleration are provided via the Coast-to-rest mode, Slow Speed with Braking, and Preset Slow Speed.
A 0-5V DC tachometer is needed for the linear speed acceleration feature, where 4.5V DC is equal to 100% speed. To prevent damage to the motor and gear, the controller has two modes that allow for adjustable deceleration: Soft Stop and Pump Stop.
Protection and Diagnostics:
The Allen-Bradley 150-F108NBD provides comprehensive diagnostic and protective functions to ensure the motors reliability and longevity. It safeguards the system from degradation and power outages, as well as line faults, voltage imbalance, and excessive starts per hour.
The controller safeguards motor performance and longevity from phase reversal, undervoltage, and overvoltage. Monitoring the controllers states, such as temperature, stall, jam, and open gate, makes finding mechanical problems that could limit operation easier.
The controllers overload, underload, and communication fault functions protect the motor and promptly address problems. These diagnostic features allow for troubleshooting and preventative maintenance, which reduces downtime and boosts productivity.
Frequently Asked Questions:
Can the auxiliary contacts on the Allen-Bradley 150-F108NBD be programmed for specific functions?
Four auxiliary contacts can be programmed with the Allen-Bradley 150-F108NBD. These can be adjusted to better suit individual operating needs and improve control schemes.
What are the maximum output power and current of the Allen-Bradley 150-F108NBD?
The Allen-Bradley 150-F108NBD can handle a maximum of 75 horsepower and 108 amperes. This feature allows it to control big industrial motors.
How does the Allen-Bradley 150-F108NBD manage thermal energy?
At a steady state, the F108NBD dissipates 91 W of heat. Its thermal management guarantees the devices longevity and helps maintain appropriate working temperatures.
Product Specifications Table:
Attributes | Specification |
---|---|
Control Voltage | 100 to 240V AC |
Auxiliary Contacts | Four fully programmable |
Communications | Two DPIs provided |
Maximum Output Power | 75HP |
Maximum Output Current | 108 A |
User Interface | Built-in LCD with backlight |
Heat Dissipation | 91 W steady state |
Weight | 15 kg |
Dimensions (W x D x H) | 196.4 mm x 212.2 mm x 443.7 mm |
Tachometer Input | 0 to 5V DC, 4.5V DC = 100% Speed |
We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
Payment options
We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.
Credit Terms
We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.
Description
Allen-Bradley 150-F108NBD
The Allen-Bradley 150-F108NBD is a state-of-the-art SMC Flex Smart Motor Controller that can maximize industrial motors performance and efficiency. This solid-state soft-start controller incorporates powerful functionality and numerous protection features, making it indispensable for a wide range of demanding applications across sectors.
Technical Specifications:
The Allen-Bradley 150-F108NBD is compatible with a wide variety of power sources because of its wide control voltage range of 100 to 240V AC. Its four completely programmable auxiliary contacts can easily be adjusted to suit intricate control systems.
To further facilitate its incorporation into preexisting configurations, the controller has communication capabilities via two DPIs (Drive Peripheral Interfaces), one for linking to supplementary human interfaces and another for creating communication networks.
To meet the demands of demanding applications, this model can manage a maximum output current of 108 A and a maximum output power of 75 HP. All the necessary controls and monitoring functions are conveniently located on the front panel, and the built-in LCD screen with a backlight makes it easy to operate.
For locations where space is limited, the units 15 kg weight, 196.4 mm width, 212.2 mm depth, and 443.7 mm height make it an ideal choice. Under typical use, the 91 W steady-state heat dissipation rating shows that thermal energy is well managed.
Operating Modes:
The 150-F108NBD offers many working modes for better motor control and protection. Soft Start or Full Voltage Start reduces mechanical stress and electrical peaks at startup. Smart Motor Braking and Current Limit Start modes enhance motor acceleration and torque management for smooth operation. Due to Dual Ramp Start and Accu-Stop, the motor may be started and stopped with pinpoint accuracy.
Applications requiring a short boost or individualized start sequences can use the controllers Selectable Kickstart and Pump Start modes. Adjustable operating speeds and gradual deceleration are provided via the Coast-to-rest mode, Slow Speed with Braking, and Preset Slow Speed.
A 0-5V DC tachometer is needed for the linear speed acceleration feature, where 4.5V DC is equal to 100% speed. To prevent damage to the motor and gear, the controller has two modes that allow for adjustable deceleration: Soft Stop and Pump Stop.
Protection and Diagnostics:
The Allen-Bradley 150-F108NBD provides comprehensive diagnostic and protective functions to ensure the motors reliability and longevity. It safeguards the system from degradation and power outages, as well as line faults, voltage imbalance, and excessive starts per hour.
The controller safeguards motor performance and longevity from phase reversal, undervoltage, and overvoltage. Monitoring the controllers states, such as temperature, stall, jam, and open gate, makes finding mechanical problems that could limit operation easier.
The controllers overload, underload, and communication fault functions protect the motor and promptly address problems. These diagnostic features allow for troubleshooting and preventative maintenance, which reduces downtime and boosts productivity.
Frequently Asked Questions:
Can the auxiliary contacts on the Allen-Bradley 150-F108NBD be programmed for specific functions?
Four auxiliary contacts can be programmed with the Allen-Bradley 150-F108NBD. These can be adjusted to better suit individual operating needs and improve control schemes.
What are the maximum output power and current of the Allen-Bradley 150-F108NBD?
The Allen-Bradley 150-F108NBD can handle a maximum of 75 horsepower and 108 amperes. This feature allows it to control big industrial motors.
How does the Allen-Bradley 150-F108NBD manage thermal energy?
At a steady state, the F108NBD dissipates 91 W of heat. Its thermal management guarantees the devices longevity and helps maintain appropriate working temperatures.
Product Specifications Table:
Attributes | Specification |
---|---|
Control Voltage | 100 to 240V AC |
Auxiliary Contacts | Four fully programmable |
Communications | Two DPIs provided |
Maximum Output Power | 75HP |
Maximum Output Current | 108 A |
User Interface | Built-in LCD with backlight |
Heat Dissipation | 91 W steady state |
Weight | 15 kg |
Dimensions (W x D x H) | 196.4 mm x 212.2 mm x 443.7 mm |
Tachometer Input | 0 to 5V DC, 4.5V DC = 100% Speed |
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
