Allen-Bradley 150-F135NBD
Allen-Bradley 150-F135NBD
Like other motor control devices used in industrial automation, the Allen-Bradley 150-F135NBD also meets stringent requirements. Thanks to its advanced features and dependable performance, this SMC smart motor controller is an all-inclusive solution for controlling motors in many applications. It is popular among field engineers and technicians because of its strong design, complete protective measures, and various communication choices.
Technical Specifications:
The Allen-Bradley 150-F135NBD motor controller delivers powerful performance with 100 HP and 135.0 A of Maximum Output Power and Current. These qualities allow the device to handle demanding industrial applications that need high power and reliable output.
The controller supports Line Voltage from 200 to 460V AC at 50 and 60 Hz and a control voltage range of 100 to 240V AC, making it adaptable to global electrical standards. Multinational applications require this versatility to work with multiple power grids.
The controllers open enclosure makes setup and maintenance easy but requires installation in dust- and moisture-free conditions. IP2X protection against electrical shock protects internal components against solid objects larger than 12.5 mm but not liquids.
The controller is 196.4 mm wide, 212.2 mm deep, and 443.7 mm tall. Its 15 kg weight makes it strong and easy to install. The units 104 W heat dissipation capacity helps manage internal temperatures and ensure reliable performance during long operation periods, boosting its industrial value.
Effective heat management prevents controller and machinery from overheating, increasing their lifespan. Two DPI ports enable efficient motor control process configuration and monitoring by connecting to an optional human interface module and integrating with broader communication networks.
Operating Conditions:
With a storage and transit temperature range of -20 °C and an operational temperature range of 23 to 122 °F, the 150-F135NBD is designed to withstand challenging situations. Reliability under different weather conditions is guaranteed by this temperature flexibility.
This motor controller is also well-suited for installations at high altitudes, as it continues to function up to 2000 meters without derating. The devices impressive shock resistance during operation”it can endure up to 5.5 G”demonstrates its resilience against the kinds of physical hits and vibrations that are typical in industrial environments.
Built-in Protection Features:
This motor controllers continuous and safe operation is ensured by its many built-in protective measures. Protecting the controller and motor against power outages, line faults, and voltage imbalances is an important part of these measures.
To stabilize the power source and keep performance consistent, the device also protects against undervoltage and overvoltage. To further improve its dependability and efficiency in intricate automation systems, the controller keeps tabs on its internal temperature in addition to the load circumstances. It has safeguards in place to prevent overload, underload, and communication failures.
Frequently Asked Questions:
Can the Allen-Bradley 150-F135NBD operate outside its rated voltage range of 200-460V AC?
The 150-F135NBD can be damaged or run inefficiently if operated outside its rated voltage range. It is imperative that you regularly verify the voltage requirements with your power source.
Is the Allen-Bradley 150-F135NBD suitable for outdoor installations?
Because of its open enclosure style, the 150-F135NBD cannot be used outside. Install it in a clean, dry place to avoid dust and moisture.
How does altitude affect the performance of the Allen-Bradley 150-F135NBD?
The 150-F135NBD can continue to operate without derating up to 2000 meters in altitude. However, performance may suffer at higher elevations because air density and cooling efficiency are both lower.
Product Specifications Table:
| Attributes | Specification |
|---|---|
| Maximum Output Power | 100 HP |
| Maximum Output Current | 135.0 A |
| Control Voltage | 100-240V AC |
| Enclosure Type | Open |
| Line Voltage | 200-460V AC, 3-Phase |
| Frequency | 50 and 60 Hz |
| Heat Dissipation | 104 W |
| Protection against Shock | IP2X |
| Weight | 15 kg |
| Dimensions (W x D x H) | 196.4 mm x 212.2 mm x 443.7 mm |
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
