Allen-Bradley 1734-AENTR
We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
Payment options
We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.
Credit Terms
We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.
Description
Industrial Automation Co. is NOT an Authorized Rockwell Distributor - we have our own unique inventory and sourcing relationships. Review our Reseller notice‚ here.
‚
- 1734AENTR
- COMMUNICATIONS ADAPTER MODULE
- 2 ETHERNET/IP PORTS CONFIGURED AS EMBEDDED SWITCH
- SUPPORTS STAR
- TREE
- LINEAR
- AND RING TOPOLOGIES
- 24 VDC
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
TECHNICAL SPECIFICATIONS
An Overview of Allen-Bradley 1734-AENTR: A Dual Ethernet POINT I/O Communication Module
The Allen-Bradley 1734-AENTR is a highly capable dual Ethernet POINT I/O communication module that delivers Ethernet/IP network connectivity with data rates ranging from 10 to 100 Mbits/s in half or full-duplex modes. This article provides an in-depth analysis of the module's features and functionalities.
Ethernet Port and Network Topologies
The 1734-AENTR module comes with two pass-through Ethernet ports with Category 5 RJ-45 connectors, configured as embedded switches that can support ring, daisy chain, linear, tree, and star network topologies. The module is part of the 1734 series of two-port communications adapters for POINT I/O modules, with Category 5-rated twisted pair cable used for interfacing. You don't need any network scheduling and routing tables.
IP Address Configuration
The module's IP address can be assigned using thumbwheel switches or the BOOT-P DHCP utility. The device is commonly configured with a static IP address, which remains the same even when the module is powered off. Alternatively, dynamic IP addresses are assigned, which can cause communication errors due to sudden changes in the IP address. A fixed IP address should be assigned to the I/O adapter to avoid unauthorized or loss of control.
I/O Data Transfer
The 1734-AENTR module is the only module in a POINT I/O system that establishes a connection to the network and the central controller. It transfers I/O data from its local I/O backplane to the controller over the network and supports simultaneous communication with different scanner modules.
POINT I/O Family of Modular I/O Products
All Point I/O automation systems are designed to supply flexibility and affordability. This product family is characterized by how much one can separate and recombine the system's components into various configurations. This feature lowers the system costs and minimizes the size of what is needed. Additionally, customization abilities for this configuration offer numerous more options and help standardization. Also, Point I/O systems are compatible with other I/O systems, which will help reduce engineering costs for designing and implementing local and local I/O infrastructure and remote and open even more possibilities.
Conclusion
The Allen-Bradley 1734-AENTR is a versatile and robust dual Ethernet POINT I/O communication module that offers Ethernet/IP network connectivity, supporting various network topologies and IP address configuration options. Its ability to transfer I/O data from its local I/O backplane to the controller over the network and support simultaneous communication with different scanner modules enhances its functionality. The POINT I/O family of modular I/O products provides added flexibility and low cost of ownership for applications.
| Manufacturer | Rockwell Automation |
| Brand | Allen-Bradley |
| Part Number/Catalog No. | 1734-AENTR |
| Series | POINT I/O |
| Module Type | Ethernet/IP Adapter Module |
| Firmware | 3.00 or Later |
| Input Voltage Rating | 24 Volts DC |
| Enclosure Rating | Open |
| Operating Temperature | -20 to 60 degrees Celsius |
| Ethernet Communication Rate | 10/100 Mbits/s, Half or Full-Duples |
| Maximum Power Consumption | 10.4 Watts at 28.8 Volts DC |
| Weight | 0.62 pounds |
| Input Overvoltage Protection | Reverse Polarity Protected |
| Isolation Voltage | 50 Volts (Continuous) |
| Maximum Expansion I/O Capacity | 63 Modules, 31 Direct Connections |
| Software | RSLogix 5000 / Studio 500 / RSLinx |
| UPC | 10612598350145 |
