1746HSCE2
HIGH SPEED COUNTER MODULE
SLC 500
4 CHANNELS
2 FAST ANALOG INPUTS
VOLTAGE/CURRENT
5V / 12V / 24V DC
2 ANALOG VOLTAGE OUTPUTS
1.5 MS MAX
1000V ISOLATION
OPEN STYLE
All products are covered by Industrial Automation Co.'s 2-Year Warranty.
Condition
SKU
Price
Warranty
Availability
Quantity
Purchase
Technical Specifications
Technical specifications for 1746-HSCE2
Manufacturer
Rockwell Automation
Module Type
High-Speed input module
Series
SLC 500
Part Number/Catalog No.
1746-HSCE2
Brand
Allen-Bradley
Module inputs:
±A1, ±B1, ±Z1, ±A2, ±B2, and ±Z2
Input Voltage, nominal
5VDC; 24VDC
Operating Voltage Range
4.2V dc to 12V dc; 10V dc to 30V dc
Min. Pulse Width
475 ns
Min. Phase Separation
200 ns
Max. Input Frequency
1 MHz
Module outputs:
Eight (8) outputs; Four (4) Virtual / Four (8) real
Output voltage range:
10-30 VDC
Inputs
4 Single-Ended and 2 Differential Quadrature
Outputs
4
Input Frequency
1 Megahertz
Backplane Current (5 Volts)
250 milliamps
Update Time
1.5 milliseconds
Slots
1
I/O Connection
1746-RT25G
Step Response
100 milliseconds in, 2.5 milliseconds out
Input Voltage
30 Volts DC
UPC
10611320083757
