Allen-Bradley 1746-NI8
We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
Payment options
We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.
Credit Terms
We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.
Description
Industrial Automation Co. is NOT an Authorized Rockwell Distributor - we have our own unique inventory and sourcing relationships. Review our Reseller notice here.
- 1746NI8
- DISCONTINUED BY MANUFACTURER
- INPUT MODULE
- 8 POINT
- ANALOG
- 20 MA
- 10 VDC
- FAST SIGNAL CONVERSION
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
TECHNICAL SPECIFICATIONS
Introduction
The Allen-Bradley 1746-NI8 is a high-performance analog I/O module from the SLC 500 series, designed to expand analog input capabilities within industrial environments. It supports a wide range of input signals and is capable of meeting complex application requirements. The module is notable for its precision and durability, making it an excellent choice for automation tasks.
Technical Specifications for Allen-Bradley 1746-NI8
The 1746-NI8 features 8 analog input channels with a broad signal range, accommodating -20 to +20 mA or -10 to +10V dc inputs. Its bandwidth supports frequencies from 1-75 Hertz, ensuring swift and accurate signal processing. The input filter frequencies range from 1 Hz up to 75 Hz, coupled with a swift 6 millisecond update time, reflecting its capability to offer rapid responses to changing conditions.
Constructed for successive approximation and switched-capacitor conversion, this module aims at high-quality signal conversion with a step response of 0.75-730 milliseconds. It boasts a 16-bit resolution, providing detailed and precise measurements. Its backplane power consumption peaks at 14 Watts, with a maximum thermal dissipation of 3.4 Watts, underlining its efficiency in operation.
Setup and Operating Climate Conditions
The module functions optimally within a specific temperature and power supply range. Installation requires careful consideration of environmental conditions, ensuring a surrounding temperature between 0 and +60 °C for optimal performance. The module's design accounts for minimal thermal dissipation and efficient power consumption, contributing to a stable operating environment. Proper grounding and shielding practices are recommended to prevent interference and ensure accurate analog input processing.
Allen-Bradley 1746-NI8 Components
Included with the 1746-NI8 module are 9 green status indicators for each of its 8 channels and one for module status, facilitating easy monitoring. The input impedance of 250 Ohms accommodates a broad range of sensors and signal sources, demonstrating the module's flexibility. Additionally, compatibility with 1492-ACABLE*C cables ensures straightforward connectivity and installation.
Enhanced Protective Functions
Designed with safety and reliability in mind, the 1746-NI8 module integrates features that safeguard against overvoltage, signal noise, and other potential hazards. Its robust construction and careful design parameters contribute to consistent operation and longevity, highlighting Allen-Bradley's commitment to quality and reliability in industrial automation solutions.
Discover More with Allen-Bradley 1746
Enhance your automation system with the Allen-Bradley 1746-NI8. Request a quote today and take the first step towards advanced analog input capabilities.
