All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
Description
Industrial Automation Co. is NOT an Authorized Rockwell Distributor - we have our own unique inventory and sourcing relationships. Review our Reseller notice here.
- 1746NIO4V
- DISCONTINUED BY MANUFACTURER 5/31/2021
- I/O MODULE
- VOLTAGE COMBINATION MODULE
- SLC 500
- HIGH RESOLUTION
- ANALOG
- 2INPUT
- 2 OUTPUT
- 24 VDC
- 115 MA
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
TECHNICAL SPECIFICATIONS
Technical specifications for 1746-NIO4V
Manufacturer | Rockwell Automation |
---|---|
Module Type | Analog combination module |
Series | SLC500 |
Part Number/Catalog No. | 1746-NIO4V |
Brand | Allen-Bradley |
No. of inputs | Two (2) Differential Voltage / Current inputs |
Current Input range | -20 to 20 mA |
Current input resolution | 1.22070 µA per LSB |
Voltage Input range | -10 to +10V dc - 1 LSB |
Voltage input resolution | 305.176 µV per LSB |
No. of Outputs | Two (2) non-isolated voltage outputs |
Output Voltage range | -10 to +10 volts |
Output voltage resolution | 1.22070 mV per LSB |
Backplane Current at 5.1 Volts | 0.55 mA |
Backplane Current at 24 Volts | 115 mA |
Inputs | 2 |
Outputs | 2 |
Backplane Current (5 Volts) | 55 milliamps |
Backplane Current (24 Volts) | 115 milliamps |
Bandwidth | 10 Hertz |
Update Time | 512 microseconds |
Resolution | 16 bits in, 14 bits out |
Step Response | 60 milliseconds in, 2.5 milliseconds out |
Mounting | Rack mount |
UPC | 10662073735899 |
