The Allen-Bradley 1746-OA16 module is designed for 16-channel current or voltage analog output. This unit offers reliable, low cost I/O solutions with superior performance. It has a high density, providing the ability to monitor and manage up to 16 isolated analog outputs.
1746OA16
I/O MODULE
16 OUTPUTS
85-265 VOLT AC
370 MA
BACKPLANE CURRENT LOAD
GENERAL PURPOSE 120/240 VOLT OUTPUT
Technical specifications for 1746-OA16
Manufacturer
Rockwell Automation
Module Type
Digital AC Output Module
Series
SLC500
Part Number/Catalog No.
1746-OA16
Brand
Allen-Bradley
No. of Outputs
Sixteen (16) outputs
Output Voltage
120/240 VAC output
Operating Voltage Range
85-264 VAC
Output Delay Time, OFF to ON
11.0 ms
Output Delay Time, ON to OFF
1 ms
OFF state leakage current
2 mA
Load Current
10 mA
Backplane Current at 5.1 Volts
0.370 A
Continuous current per point
0.50 A @ 30 °C (86 °F) 0.25 A @ 55 °C (131 °F)
Continuous current per module, max
8.0 A @ 30 °C (86 °F) 4.0 A @ 60 °C (140 °F)
Voltage Range
85 to 265 Volts AC
Outputs
16
Current/Output at 30 degrees Celsius
0.5 Amps
Current/Output at 60 degrees Celsius
0.25 Amps
Backplane Current (5 Volts DC)
370 milliamps
Current/Module (30 degrees Celsius)
8 Amps
Applications
General Purpose
Step Response
60 milliseconds in, 2.5 milliseconds out
Ambient Operating Temperature
32 to 140 degrees Fahrenheit
UPC
10662468067062
UNSPSC
32151705
