Allen-Bradley 1746-P2
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
Description
Industrial Automation Co. is NOT an Authorized Rockwell Distributor - we have our own unique inventory and sourcing relationships. Review our Reseller notice here.
- 1746P2
- POWER SUPPLY
- SLC RACK MOUNTING
- 85-132 / 170-265 VAC LINE VOLTAGE
- 47-63 HZ
- 180 VA TYPICAL LINE POWER REQUIREMENT
- 20 AMP MAX INRUSH CURRENT
- 5 AMP 5 VDC / 0.96 AT 24 VDC OUTPUT
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
TECHNICAL SPECIFICATIONS
| Manufacturer | Industrial Automation |
| Brand | Allen-Bradley |
| Part Number/Catalog No. | 1746-P2 |
| Series | SLC 500 |
| Module Type | Power Supply |
| Input Power | 70 Watts |
| Input Voltage | 120 to 220 Volts AC |
| Typical line power requirement | 180VA |
| Inrush Current | 20 Amps |
| Backplane Current (5 Volts) | 5 amps |
| Internal Current Capacity | 5 A at 5V dc; 0.96 A at 24V dc |
| Output Voltage Range | 18 to 30 Volts DC |
| CPU Hold up time | 20 ms (full load) 3000 ms (no load) |
| Backplane Current (24 Volts) | 0.46 Amps |
| Frequency | 47 to 63 Hertz |
| Location | 1746 Chassis |
| UPC | 10662468088326 |
| Weight | 1.1 kg or 2.5 lbs. |
| UNSPSC | 32151706 |
| Dimensions | 5.5 x 3.3 x 5.7 inches |
| Operating Temperature | 0 to 60 Celsius |
| Fuse Protection | 1746-F1 or equivalent |
| Programming Software | RSLogix 500 |
