Allen-Bradley 1756-EN2T
We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
Payment options
We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.
Credit Terms
We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.
Description
The Allen-Bradley 1756-EN2T module is a cutting-edge communication solution for industrial environments, ensuring secure and high-speed Ethernet connectivity. It supports Ethernet/IP and TCP/IP protocols, enhancing reliable communication across your facility's network. With capabilities for up to 128 TCP and 256 CIP connections, this module is built for efficient network traffic management. Its diagnostic features are designed for rapid issue identification, streamlining maintenance and minimizing downtime. Experience seamless integration and optimized network performance with the 1756-EN2T.
- 1756EN2T
- INTERFACE MODULE
- COMMUNICATIONS
- CONTROLLOGIX
- ETHERNET/IP BRIDGE
- 10/100 MBPS
- 256 LOGIX COMMUNICATIONS
- 128 TCP/IP CONNECTIONS
- REPLACES 1756-ENBT
Industrial Automation Co. is NOT an Authorized Rockwell Distributor - we have our own unique inventory and sourcing relationships. Review our Reseller notice here.
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
TECHNICAL SPECIFICATIONS
The Allen-Bradley 1756-EN2T Ethernet Industrial Protocol (EtherNet/IP) interface communication module allows for general and real-time I/O messages as well as information transmission for RCS (Real-Time Control Systems) and applications using time synchronization and motion. Additionally, it has the CIP (Common Industrial Protocol) safety standard, which enables fail-safe communication among various nodes on a safety network. It makes use of physical media and cutting-edge communication chips.
Twisted pair cables are used in the 1756-EN2T communication module, which supports EtherNet/IP communication speeds of 10-100 Mbps. It supports 128 TCP/IP connections and 256 Logix connections. It consumes 1 A of electricity at 5.1V dc and supports up to 8 axes of integrated motion across an Ethernet/IP network.
It can dissipate 5.1 Watts of electricity at its maximum and 17.4 BTU of heat per hour. In the ControlLogix chassis, it may be inserted into any available slot. It connects to the controller using category five twisted-pair cables with unshielded RJ45 (Registered Jack 45) connectors for wiring.
The 1756-EN2T interface communication module is configured at the workstation using RSLinx software. EtherNet/IP networks require the configuration of several parameters, including subnet masks, IP addresses, and a gateway. The 1756-EN2T bridge can manage messages, distributed I/O, and tagging, among other things. Messages are incorporated into the common TCP/IP protocol.
It may share a common application layer due to the ControlNet and DeviceNet networking protocols. Information storage does not require a scheduling or routing table. This module has additional features of a secured mode, electronic keying, a device-level ring network, and support for parallel redundancy protocol networks.
The ControlLogix 1756-EN2T interface communication module supports the Ethernet I/P protocol. It is possible to install this single-slot module in any available slot on a ControlLogix chassis. It includes a single RJ45 connection for connecting to an Ethernet network. Additionally, it contains a USB 1.1 connector that may initially be used to set up the module.
Multiple connections for distributed Input/Output clients, SCADA (Supervisory Control and Data Acquisition), HMI (Human Machine Interface), and external devices may be made simultaneously using a 1756-EN2T interface communication module.
A network with a linear topology can be attached to this module. Any ControlLogix chassis, including the 1756-A13, 1756-A4, 1756-A17, 1756-A7, and 1756-A10, and ControlLogix power supplies, including the 1756-PB75, 1756-PB72, 1756-PH75, 1756-PC75, 1756-PA75, 1756-PB75 and 1756-PA72 are compatible with it.
| Manufacturer | Industrial Automation |
| Brand | Allen-Bradley |
| Part Number/Catalog No. | 1756-EN2T |
| Series | ControlLogix |
| Product Type | Ethernet Communication Module |
| Ethernet-IP Communication Rate | 10/100 Mbps |
| Insulation Voltage | 30 Volts Continuous |
| Integrated Ports | One (1) RJ45; One (1) USB 1.1 |
| Current Draw | 1 Amp |
| Location | Chassis (any slot) |
| Current Rating | 1.2 Amps |
| Slot Width | 1 |
| Operating Temperature | 32 to 140 degrees Fahrenheit (0 to 60 degrees Celsius) |
| UPC | 10612598329103 |
| Power Dissipation | 6.2 W |
| UNSPSC | 32151705 |
| Thermal Dissipation | 21.28 BTU per hour |
| Configuration Software | RSLogix 5000; Studio 5000 Logix Designer |
