1756ENBT
DISCONTINUED BY MANUFACTURER 12/31/2021
ETHERNET/IP COMMUNICATION BRIDGE MODULE
CONTROLLOGIX
10/100 MBPS
24 VDC
3 MA
128 LOGIX CONNECTIONS
REPLACED BY 1756-EN2T
Technical Specifications
Manufacturer
Industrial Automation
Brand
Allen-Bradley
Part Number/Catalog No.
1756-ENBT
Module Type
Ethernet Communication Module
Series
ControlLogix
Current Draw (5.1 Volt DC)
700 milliamps
Ethernet-IP Communication Rate
10/100 Mbps
Current Draw (24 Volt DC)
3 milliamps
Integrated Ports
One (1) RJ45; One (1) USB 1.1
Current Draw
700 mA
Insulation Voltage
30 Volts Continuous
Enclosure
Open
Location
Chassis (any slot)
Slot Width
1
Operating Temperature
32 to 140 degrees Fahrenheit (0 to 60 degrees Celsius)
Power Dissipation
3.7 W
Firmware Revision
Any
Thermal Dissipation
12.6 BTU/hr
RSLogix 5000 Software
Verson 8.02.00 or later
Configuration Software
RSLogix 5000; Studio 5000 Logix Designer
UPC
10612598269485
UNSPSC
32151705
