Allen-Bradley 1756-IB16I
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
Description
Industrial Automation Co. is NOT an Authorized Rockwell Distributor - we have our own unique inventory and sourcing relationships. Review our Reseller notice here.
- 1756IB16I
- INPUT MODULE
- CONTROLLOGIX
- DC DIGITAL
- 16 POINT
- 10-30V DC
- INDIVIDUALLY ISOLATED
- INPUT AND COMMUNICATION STATUS AND MODULE HEALTH DISPLAY
- DIGITAL
- 36 PIN
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
TECHNICAL SPECIFICATIONS
| Manufacturer | Rockwell Automation |
| Brand | Allen-Bradley |
| Part Number/Catalog No. | 1756-IB16I |
| Series | ControlLogix |
| Module Type | Digital DC Isolated Input Module |
| Inputs | 16 Individually Isolated Inputs |
| Input Voltage | 12-24 Volts DC Sink-Source |
| Operating Voltage Range | 10-30 Volts DC |
| Input Delay Time | 4 milliseconds plus selected filter time |
| Minimum Operating Current | 2 milliamperes at 10 Volts DC |
| Maximum Operating Current | 10 milliamperes at 30 Volts DC |
| Maximum Input Current, Off-State | 1.5 milliamperes |
| Power Dissipation (Max) | 5 Watts at 60 degrees Celsius |
| Removeable Terminal Block(s) | 1756-TBCH, 1756-TBS6H |
| RSLogix 5000 Software | Verson 8.02.00 or later |
| UPC | 10612598164506 |
