Description
The Allen-Bradley 1756-IB16ISOE ControlLogix Digital I/O Module offers 16 individually isolated inputs with high precision event timestamping capabilities in either UTC or CST, achieving sub-millisecond accuracy, ideal for monitoring time-critical applications. It operates within a voltage range of 10 to 55V DC, with nominal input voltage at 24V DC, and handles both sink and source types, delivering reliable performance with a current draw of 320 mA at 5.1V and 2mA at 24V. This module, designed for real-time event logging while providing basic ON/OFF detection, efficiently dissipates power at 17.22 BTU/hour and features a robust build to handle thermal dissipation at 5.5 W at 60°C.
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
TECHNICAL SPECIFICATIONS
Manufacturer | Rockwell Automation |
Brand | Allen-Bradley |
Part Number/Catalog No. | 1756-IB16ISOE |
Series | ControlLogix |
Module Type | Digital DC Isolated Input Sequence of Events |
Inputs | 16 Individually Isolated; Sequence of Events |
Input Voltage | 24-48 Volts DC Sink-Source |
Operating Voltage Range | 10-55 Volts DC |
Input Delay Time | 50 microseconds plus selected filter time |
Minimum Operating Current | 5.5 milliamperes at 55 Volts DC |
Maximum Operating Current | 2 milliamperes at 10 Volts DC |
Maximum Input Current, Off-State | 1.5 milliamperes |
Power Dissipation (Max) | 5.5 Watts at 60 degrees Celsius |
Backplane Current at 5 Volts | 275 milliamperes |
Backplane Current at 24 Volts | 2 milliamperes |
Removeable Terminal Block(s) | 1756-TBCH, 1756-TBS6H |
RSLogix 5000 Software | Verson 8.02.00 or later |
UPC | 10612598299666 |
