Description
The Allen-Bradley 1756-IF8IH is a sophisticated HART Analog I/O Module designed for seamless integration with the ControlLogix system, featuring 8 current input channels and a HART modem per channel. This module supports versatile input ranges of 0 to 20 milliamps or 4 to 20 milliamps and offers flexibility with four selectable data formats, making it suitable for various applications. With advanced signal processing including individual ADC and digital filters for each channel and real-time sampling capabilities, the 1756-IF8IH ensures accurate and reliable data communication with HART-enabled devices at revisions 5, 6, or 7, while managing under-range, over-range, and open-circuit conditions effectively.
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
TECHNICAL SPECIFICATIONS
Manufacturer | Rockwell Automation |
Brand | Allen-Bradley |
Part Number/Catalog No. | 1756-IF8IH |
Series | ControlLogix |
Module Type | Hart Isolated Analog Input Module |
Channels | 8 Isolated Differential |
Input Range | 0-20 or 4-20 milliamps |
Resolution | 16-21 bits |
Enclosure | Open |
Overvoltage Protection | (+/-) 24 Volts |
Resolution | 16-21 bits |
Enclosure | Open |
RSLogix 5000 Software | Verson 8.02.00 or later |
