Description
The Allen-Bradley 1756-IV32 is a robust digital input module designed for integration within the ControlLogix 1756 chassis, featuring 32 inputs divided into two groups of 16. This 12/24 Volt DC source module operates within a voltage range of 10 to 30 Volts DC and requires either a 1756-TBCH or 1756-TBS6H removable terminal block for proper connection. It draws 120 milliamps at 5.1 Volts and 2 milliamps at 24 Volts, with a backplane power consumption of 0.66 Watts and a power dissipation of up to 4.1 Watts at 60°C. The module supports a nominal input voltage of 24 Volts DC and exhibits efficient current handling with a maximum inrush of 250 milliamps, quickly reducing to less than 37% within 22 milliseconds. For optimal signal processing, it features a configurable screw-to-backplane input delay and can handle a thermal dissipation of 14 BTU/hour at high operating temperatures.
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
TECHNICAL SPECIFICATIONS
Manufacturer | Rockwell Automation |
Brand | Allen-Bradley |
Part Number/Catalog No. | 1756-IV32 |
Series | ControlLogix |
Module Type | Digital DC Input Module |
Inputs | 32 |
Input Voltage | 12-24 Volts DC |
Operating Voltage Range | 10-30 Volts DC |
Input Delay Time | 2 milliseconds plus selected filter time |
Minimum Operating Current | 2 milliamps at 10 Volts DC |
Maximum Operating Current | 3.5 milliamps at 30 Volts DC |
Maximum Input Current, Off-State | 1.5 milliamps |
Power Dissipation (Max) | 4.1 Watts at 60 degrees Celsius |
Backplane Current at 5 Volts | 120 milliamps |
Backplane Current at 24 Volts | 2 milliamps |
Removeable Terminal Block(s) | 1756-TBCH, 1756-TBS6H |
RSLogix 5000 Software | Verson 8.02.00 or later |
UPC | 10612598264350 |
