Allen-Bradley 1756-L83ES
Allen-Bradley 1756-L83ES
The GuardLogix 5580 Controller (1756-L83ES) is a high-performance unit within the controllers series by Allen-Bradley. This controller is specifically designed to meet the demands of modern manufacturing environments, prioritizing efficiency, safety, capacity, and performance.
Technical Specifications:
The 1756-L83ES has 10 MB of regular memory and 5 MB of spare memory, so it can handle complicated applications with ease. Its 1 GB Ethernet port and 12 Mbps USB 2.0 port improve its connection and data transmission capacities.
This controller is ideal for large-scale industrial networks because it can accommodate up to 250 EtherNet/IP devices. With a maximum of 128,000 digital I/O and 4,000 analog I/O, it provides flexibility for connecting to a wide range of sensors and actuators. Additional storage and configuration options are provided via the unit's pre-installed 2GB Secure Digital Card (1784-SD2).
Applications necessitating high-performance I/O, motion control, and communications will find these controllers to be suitable. They are tailor-made to meet the increasing requirements of smart equipment and sophisticated production methods.
Its integration with Studio 5000 Automation Engineering & Design Environment highlights its suitability for complicated automation jobs and high-speed motion applications. The controller's usability in different industrial contexts is further enhanced by its interoperability, guaranteeing a seamless design and configuration experience.
The 1756-L83ES is well-suited to a variety of industrial settings, as it functions efficiently from 0 to 60 degrees Celsius. This adaptability guarantees dependable operation in many kinds of environments.
Built-In Safety Features:
The 1756-L83ES stands out among industrial controllers thanks to its sophisticated safety features. Its separate safety memory ensures high dependability and prioritizes safety functions by separating standard processing from safety-related processes.
Having a specialized system to handle safety measures efficiently is essential in workplaces where safety is vital, and this feature delivers just that. The controller is a dependable option for essential safety applications in different industrial settings since it conforms to strict safety regulations and satisfies specified safety integrity level (SIL) and performance level (PL) requirements.
Grounding and Wiring:
Important parts of installing and operating the 1756-L83ES include wiring and grounding. Proper grounding is critical to prevent electrical hazards and reduce performance-degrading electrical noise. In accordance with both state and federal electrical regulations, the controller must be grounded. To do this, you must ensure that all system components are properly grounded and connect the grounding wire to an appropriate earth ground.
Conversely, wiring has to be done with great care to guarantee that all connections are safe and set up correctly. Everything from the power supply to the input/output modules and the connections to the network are part of the wiring. Must follow Rockwell Automation's instructions to the letter to prevent damage and guarantee dependable operation.
Frequently Asked Questions:
How much RAM the Allen-Bradley 1756-L83ES can hold?
A total of 10 MB of regular memory and 5 MB of safety memory are available to users of the 1756-L83ES. This capacity allows for versatile program execution and robust safety protocols.
What kinds of ports can I use to connect to other devices on the 1756-L83ES?
An RJ-45 10/100/1000 Mbps Ethernet port and a USB 2.0 port are available on the 1756-L83ES. These facilitate high-speed connectivity for data exchange and programming interfaces.
Is the 1756-L83ES sent with a digital security card already installed?
An internal 2 GB Secure Digital Card (1784-SD2) is already present in the controller upon shipment. This embedded security card enhances data protection and storage capabilities.
Product Specification Table
| Attributes | Specification |
|---|---|
| Series | GuardLogix 5580 |
| Communication Interface | 1 x USB 2.0 Port, 1 x RJ-45 10/100/1000 Mbps Ethernet |
| Software Compatibility | Studio 5000 Automation Engineering and Design Environment |
| Ambient Temperature Range | 32 to 140 degrees Fahrenheit (0 to 60 degrees Celsius) |
| Communication Interface | EtherNet/IP nodes support (up to 250 nodes) |
| Mounting Type | Chassis Mount |
| User Memory | 10MB Standard Memory and 5MB Safety Memory |
| Maximum Digital I/O | 128000 |
| Maximum Analog I/O | 4000 |
| USB Port | 12 Mbps USB 2.0 port |
