Allen-Bradley 1756-OA8E
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
Description
Industrial Automation Co. is NOT an Authorized Rockwell Distributor - we have our own unique inventory and sourcing relationships. Review our Reseller notice, here.
The Allen-Bradley 1756-OA8E is a versatile ControlLogix discrete output module designed for industrial automation systems, featuring eight channels that provide a nominal 120 VAC output with an operating range from 74 to 132 VAC at frequencies of 47-63 Hz. This module supports a total module current of 8A at 30°C and 4A at 60°C, with an output delay time of 9.3 ms at 60 Hz and 11 ms at 50 Hz, ensuring rapid response to control signals. Compatible with the 1756 chassis, it maintains a backplane power requirement of 7.02 Watts, incorporates electronic fusing for individual channel protection, and requires 1756-TBNH or 1756-TBSH removable terminal blocks for connections.
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
TECHNICAL SPECIFICATIONS
| Manufacturer | Rockwell Automation |
| Brand | Allen-Bradley |
| Part Number/Catalog No. | 1756-OA8E |
| Series | ControlLogix |
| Module Type | Electronic Fused AC Output Module |
| Outputs | 8-Point Electronic Fusing |
| Voltage | 120 Volts AC |
| Operating Voltage Range | 74-132 Volts AC |
| Maximum Output Current Rating-Point | 2 Amps at 60 degrees Celsius |
| Maximum Output Current Rating-Module | 8 Amps at 30 degrees Celsius and 4 Amps at 60 degrees Celsius |
| Power Dissipation (Max) | 5.5 Watts at 60 degrees Celsius |
| Backplane Current at 5 Volts | 200 milliamps |
| Backplane Current at 24 Volts | 250 milliamps |
| Removeable Terminal Block(s) | 1756-TBNH, 1756-TBSH |
| Isolation Voltage | 50 Volts Continuous |
| Enclosure | None |
| UPC | 10612598171399 |
