Allen-Bradley 1756-OF6VI
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
Description
The Allen-Bradley 1756-OF6VI is an advanced ControlLogix voltage loop analog output module, perfect for demanding applications requiring precision. With six individually isolated output channels, it offers a wide output range of +/- 10 VDC and a 14-bit resolution, ensuring high fidelity in signal conversion. It excels in performance with a fast settling time below 2 ms, high calibration accuracy, and robust protections like overvoltage and short circuit safeguards. Designed to fit into any ControlLogix chassis slot, the module supports loads greater than 1000 ohms and features an efficient 5.5-watt power consumption. Its operational resilience is highlighted by its ability to function within a 0 to 60°C range and resist vibrations and shocks, making it a reliable choice for complex industrial environments.
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
TECHNICAL SPECIFICATIONS
| Manufacturer | Rockwell Automation |
| Brand | Allen-Bradley |
| Part Number/Catalog No. | 1756-OF6VI |
| Series | ControlLogix |
| Module Type | Isoloated Analog Output Module with voltage loop |
| Outputs | 6-Point Isolated |
| Backplane Current (5Volts) | 250 milliamps |
| Backplane Current (24 Volts) | 175 milliamps |
| Power Dissipation (Max) | 4.85 Watts |
| Removable Terminal Blocks | 1756-TBNH, 1756-TBSH |
| Power Dissipation (Max) | 4.9 Watts at 60 Celsius |
| Removeable Terminal Block(s) | 1756-TBNH, 1756-TBSH |
| Isolation Voltage | 50 Volts Continuous |
| Enclosure | None |
| UPC | 10612598164667 |
