Allen-Bradley 1756-OF8H

Allen-Bradley 1756-Of8H Plc

Allen-Bradley 1756-OF8H

Regular price
$2,288.00
Sale price
$2,288.00
We currently have 1 in stock.
Checkmark

In stock - Ships Today

Checkmark

Eligible for Next Day Delivery

Checkmark

Ships From Our North Carolina Warehouse

Eligible for Next Day Delivery All Parts Come with 24 Month Warranty New, Refurbished and Repairs Available


We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.


All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.


Payment options

We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.

Credit Terms

We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.

Description

Industrial Automation Co. is NOT an Authorized Rockwell Distributor - we have our own unique inventory and sourcing relationships. Review our Reseller notice€š here.


  • 1756OF8H
  • OUTPUT MODULE
  • CONTROLLOGIX
  • ANALOG
  • 8 POINT
  • SINGLE ENDED POINT OUTPUTS
  • HART PROTOCOL
  • CURRENT AND VOLTAGE

Buying Options
Buying Options

All products are covered by Industrial Automation Co.'s 2-Year Warranty.

Condition SKU Price Warranty Availability Quantity Purchase
Surplus Original Box 1756-OF8H-FS $2,288.00 USD 2 Year Extended Warranty 1 In Stock in the U.S.A!
Quick Repairs and Great Service

Send in your item for a free evaluation and repair quote. Use our RMA form or email a repair request to service@iac.us.com , and we will contact you to assess your situation and offer shipping information.

Quick Search

All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.


TECHNICAL SPECIFICATIONS

The Allen-Bradley 1756-OF8H analog output module features 8 channels that may be either for current or voltage. They can be set up with 0...20 mA or 4...20 mA current signals and ±10V dc voltage signals. Every module channel supports the Highway Addressable Remote Transducer (HART) Communication Protocol, making it possible to link HART-capable equipment, including communicators, to obtain module data and state and connect to the software program.

On all signal ranges, the 1756-OF8H analog output module has a module resolution of 15 or 16 bits. It contains an internal digital-to-analog converter (DAC) that uses the R-Ladder monotonicity using the no missing codes conversion technique and the IEEE 32-bit floating-point data format.

This module only takes up one slot on a ControlLogix 1756 chassis when installed. It can function as a local or remote Input/Output module component. This module contains a removable terminal block (RTB) for the termination of signal wires. This RTB may be swapped out for either the 1756-TBNH or the 1756-TBSH using user-defined physical RTB keying.

When 1756-TBNH is utilized, 0.33-2.1 mm2 (22-14 AWG) for single-wire connections and 0.3-1.3 mm2 (22-16 AWG) for double-wire connections are the appropriate wire sizes. The 1756-TBSH is designed for wire sizes ranging from 0.33 to 1.3 mm2 (22 to 16 AWG) and only enables single wire connections.

The continuous isolation voltage rating for the 1756-OF8H analog output module is 50V. Module isolation only applies to output channels to the backplane. None of the output channels have personal isolation. Additionally, the module's open circuit detection time is only usable with the current setup, and the overvoltage protection is limited to up to ±24V dc at its highest level.

The backplane current consumption for the 1756-OF8H ControlLogix voltage/current analog output module is 230 mA at 5.1V dc and 230 mA at 24V dc, with a 6.54 Watts backplane power. It dissipates 4.92 Watts of electricity and 16.78 BTU of heat each hour. The fundamental insulation between the output channels and the backplane of the 1756-OF8H analog output module was tested at 1500V ac for the 60s and had an isolation value of 50V.

The 1756-OF8H analog output module supports Open-Circuit Detection with a detection time of less than 0.1 mA. Its voltage settles in 8.5 ms, while its current settling time is slightly under 23 ms without HART and below 37 ms with HART. Its standard calibration interval is roughly 12 ms, and its calibration accuracy (without HART) is 0.1% for voltage and 0.15% for current.

The offset drift for the 1756-OF8H analog output module is 100V per °C or 200 nA per °C, and the total module error is 0.15% (voltage) or 0.3%. (current). Although it uses user-defined mechanical keying, the module keying may be adjusted electrically and through software. The temperature code is ATEX, T4 North America, and IEC, and it is approved for open-style enclosures. The 1756-OF8H can operate in a range of temperatures between 0 °C and 60 °C with a relative humidity of 5 to 95%.

ManufacturerRockwell Automation
BrandAllen-Bradley
Part Number/Catalog No.1756-OF8H
SeriesControlLogix
Module TypeHart Analog Output Module
Outputs8 Differential
Input Current Range0-20 or 4-20 milliamps
Isolation Voltage50 Volts Continuous
Overvoltage Protection24 Volts DC
Enclosure Open
Removeable Terminal Blocks1756-TBNH, 1756-TBSH
Removeable Terminal Block(s)1756-TBNH, 1756-TBSH
Isolation Voltage50 Volts Continuous
EnclosureNone
UPC10612598345486
