Allen-Bradley 1756-TBCH
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
Description
The Allen-Bradley 1756-TBCH is a 36-pin cage-clamp Removable Terminal Block (RTB) designed for modular and flexible wiring connections in ControlLogix I/O modules. This component, essential for interconnecting 1756 I/O modules with industrial plant wiring, installs easily into the front of an I/O module, enabling wire termination without detaching the main module. Supporting a variety of ControlLogix modules such as the 1756-IA16I and 1756-OB16IEF, the 1756-TBCH ensures efficient and secure connection with a 0.5 Nm screw torque and accommodates copper wire sizes from 0.33 to 2.1 mm². It operates in clean, dry environments with a temperature range of 0-60°C and withstands 30g shock, making it suitable for various high-speed digital processing and process control applications.
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
TECHNICAL SPECIFICATIONS
| Manufacturer | Rockwell Automation |
| Brand | Allen-Bradley |
| Part Number/Catalog No. | 1756-TBCH |
| Series | ControlLogix |
| Module Type | Terminal Block |
| Clamp Type | Screw-Clamp |
| Pins | 36-Pin Connection |
| Screw Torque | 0.5 Nm (4.4 lb/in) |
| Single Wire Connection | 0.33 to 2.1 mm. sq. (22…14 AWG) |
| Double wire connection | 0.33 to 1.3 mm. sq. (22…16 AWG) |
| Wire Type | Solid or Stranded Wire |
| Max. Wire Insulation | 90 °C (194 °F) or greater, 1.2 mm (3/64 in.) |
| Recommended Tool | Screwdriver |
| Operating Temperature | 32-140 Fahrenheit (0-60 Celsius) |
| Screwdriver width | 3.2 mm (1/8 in.) |
| Enclosure | None |
| Weight | 0.3 pounds (0.1 kilograms) |
| UPC | 10612598171832 |
| Backplane Current (5Volts) | 1,200 milliamps |
| Backplane Current (24 Volts) | 2.5 milliamps |
| Power Dissipation (Max) | 6.19 Watts |
| Wire Size | 20 AWG |
| Dimensions | 5.51 x 4.41 x 5.71 inches |
