Allen-Bradley 1761-L16AWA
We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
Payment options
We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.
Credit Terms
We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.
Description
The Allen-Bradley MicroLogix 1761-L16AWA is a compact and versatile PLC designed for micro and small-scale automation applications. This controller features 16 integrated I/O points, comprising 10 AC inputs and 6 relay outputs, with AC power supply options ranging from 85 to 264 Volts. Equipped with a 1K EEPROM memory capable of storing up to 737 instructions and 437 data words, the 1761-L16AWA supports complex control functions including discrete and analog processing, with an impressive scan time of 2 milliseconds. Its robust design incorporates features such as LED status indicators, a master control relay for safety shutdowns, and the ability to withstand harsh environmental conditions, including a wide operating temperature range and vibration resistance. Ideal for setups requiring reliable and efficient control, this MicroLogix 1000 controller is compatible with a variety of cabling options and should be installed within a NEMA-rated enclosure for enhanced protection.
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
TECHNICAL SPECIFICATIONS
| Manufacturer | Rockwell Automation |
| Brand | Allen-Bradley |
| Part Number/Catalog No. | 1761-L16AWA |
| Series | MicroLogix 1000 |
| I/O Count | 16-points |
| Memory: | 1 K EEPROM composed of approximately 737 instruction words and 437 data words. |
| Input Type | 120 Volts AC |
| Communication port: | RS232 |
| Protocol: | DF1 |
| Safety Feature | Master Control Relay |
| Product Type | Programmable Logic Controller (PLC) |
| Digital Outputs | 6 Contact Outputs |
| No. of Inputs | Sixteen (16) sinking |
| Output Type | Six (6) Relay |
| Power Supply | 120/240 Volts AC |
| Operating Frequency: | 47-63 Hz |
| Input Power | 7 Watts |
| Measurements | 5.24 x 2.87 x 3.15 inches |
| UPC | 10662468368688 |
| Weight | 1.40 pounds |
| Product Lifecycle Status* | Discontinued/Obsolete |
| Operating Shock | 10 G |
| Non-Operating Shock | 20 G |
*The Allen Bradley 1761-L16AWA has been discontinued by the manufacturer, however we specialize in obsolete parts and can likely still supply surplus and/or refurbished replacement 1761-L16AWA units instead of migration.
