Allen-Bradley 1761-L20AWA-5A
We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
Payment options
We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.
Credit Terms
We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.
Description
The Allen-Bradley 1761-L20AWA-5A MicroLogix 1000 Controller is a versatile PLC that operates on an AC power supply and features both discrete and analog control capabilities. It includes twelve AC inputs, four analog inputs, eight relay outputs, and one analog output, alongside a DF1 RS-232 communication port for flexible interfacing. With a compact design measuring 7.87 x 2.87 x 3.15 inches, this controller is capable of executing complex programs involving bit logic operations, timers, counters, and data handling with its 1K EEPROM memory. It supports 120/240 Volts AC line voltage and can handle a wide operating temperature range, making it suitable for various industrial applications.
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
TECHNICAL SPECIFICATIONS
| Manufacturer | Rockwell Automation |
| Brand | Allen-Bradley |
| Controller | MicroLogix 1000 |
| Part Number/Catalog No. | 1761-L20AWA-5A |
| I/O Count | 20 points |
| Input Type | 120V ac |
| Memory: | 1 K EEPROM composed of approximately 737 instruction words and 437 data words. |
| Communication port: | RS232 |
| Analog Circuits | 4 Inputs, 1 Output |
| Protocol: | DF1 |
| Safety Feature | Master Control Relay |
| Product Type | Programmable Logic Controller (PLC) |
| Digital Outputs | 8 Contact Outputs |
| No. of Discrete Inputs | Twelve (12) |
| Dimensions (L x D x H) | 7.87 x 2.87 x 3.15 inces |
| Input Voltage Type | 120 Volts AC |
| Voltage Range | 79-132 Volts AC |
| Output Type | Eight (8) Relay |
| UPC | 10662072766498 |
| Discrete Output Voltage | 24-125 VDC; 0-240VAC |
| Analog Input | Four (4) |
| Product Lifecycle Status* | Discontinued/Obsolete |
| Analog Input Signals | Voltage -10.5 to +10.5V dc - 1LSB; Current 21 to +21 mA - 1LSB |
| Data Type | 16-bit signed integer |
| Input Coding | -32,768 to +32,767 |
| Analog Output | One (1) |
| Power Supply | 120/240 Volts AC |
| Analog Output signal | 0 to 10V dc -1LSB; 4 to 20 mA - 1LSB |
*The Allen Bradley 1761-L20AWA-5A has been discontinued by the manufacturer, however we specialize in obsolete parts and can likely still supply surplus and/or refurbished replacement 1761-L20AWA-5A units instead of migration.
