Allen-Bradley 1762-L40BWA
We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
Payment options
We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.
Credit Terms
We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.
Description
The 1762-L40BWA, part of the Allen-Bradley MicroLogix 1200 series, is a versatile PLC featuring 40 input and output channels, including 24 discrete inputs and 14 discrete outputs. It utilizes 24VDC for input interfacing with sinking and sourcing configurations, while outputs are designed for 25-125 VDC or 120-240 VAC with a durable mechanical lifespan of 20 million cycles, supporting a minimum 10A load. Equipped with an 8-pin Mini DIN RS232 communication port, this controller supports DH-485, DF1, Modbus, and ASCII protocols in a peer-to-peer setup, with capability for serial port multiplexing using various converters for broader device communication.
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
TECHNICAL SPECIFICATIONS
| Manufacturer | Rockwell Automation |
| Brand | Allen-Bradley |
| Input Power | 120 to 240 Volts AC |
| Part Number/Catalog No. | 1762-L40BWA |
| Inputs | (20) 24 Volts DC and (4) Fast 24 Volts DC |
| Outputs | (16) Relay |
| No. of Inputs | Twenty-Four (24) |
| No. of Outputs | Sixteen(16) |
| Operating Temperature | 0 to 50 degrees Celsius |
| Input Circuit Type | 24 Volts DC Sink/Source |
| Operating Frequency | 47 to 63 Hertz |
| Output Circuit Type | Relay |
| Internal Power Supply | Yes |
| Relay Contact Rating | 24-125VDC; 120-240VAC |
| UPC | 10612598207234 |
| Mechanical Cycles | 20,000,000 |
| Dimensions | Height: 90 mm 104 mm (with DIN latch open); Width: 160 mm; Depth: 87 mm |
| Load Current | 10A, minimum |
| Shipping Weight | 2.4 pounds |
| Ambient Operating Temp | 0 to 55 degrees Celsius |
| Power Supply Usage | 82 VA |
| Power supply inrush current | 120V ac: 25A for 8 ms; 240V ac: 40A for 4 ms |
| Programming Software | RSLogix 500 |
