Description

The 1762sc-IF8U is an 8-input module compatible with the Micrologix series, designed by Spectrum Controls, an Allen-Bradley encompass partner. This versatile module supports multiple input types, including voltage, current, and thermocouple, and offers flexible channel configurations, optimizing it for diverse industrial applications. It withstands temperatures up to 60°C and vibrations from 10 to 500 Hertz, operates reliably at altitudes up to 2000 meters, and requires proper grounding to prevent electromagnetic interference. For seamless installation, it mounts on a DIN rail or plate and benefits from short cable connections and proximity to input devices for accurate signal processing.


Buying Options
Buying Options

All products are covered by Industrial Automation Co.'s 2-Year Warranty.

Condition SKU Price Warranty Availability Quantity Purchase
Surplus Original Box 1762SC-IF8U-FS 2 Year Extended Warranty Call for Availability Call for Availability (877)-727-8757
Quick Repairs and Great Service

Send in your item for a free evaluation and repair quote. Use our RMA form or email a repair request to service@iac.us.com , and we will contact you to assess your situation and offer shipping information.

Quick Search

All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.


TECHNICAL SPECIFICATIONS

ManufacturerSpectrum Controls
BrandAllen-Bradley
Part Number/Catalog No.1762sc-IF8U
Product TypeUniversal Analog Input Module
Product TypeUniversalAnalog Input Module
Industrial Automation Compatible Series1762 MicroLogix
Channels8
No. of ChannelsEight (8)
Input Types8 V, C, or TC, or 4 RTD/Res (2, 3 or 4-wire)
Input Current0 to 20 mA
Compatible Input SignalsVoltage, Current, Thermocouple, RTD, Resistance
Voltage Input Signal ranges±50 mV, ±100 mV, 0 to 5 V, 1 to 5 V, ±10 V and 0 to 10 V
Voltage0 to 5 Volts
Current Input signal ranges4 to 20 mA and 0 to 20 mA
Thermal Dissipation1.4 W maximum
Compatible RTD Sensors100 ? Pt ? 0.385, 200 ? Pt ? 0.385, 500 ? Pt ? 0.385, 1000 ? Pt ? 0.385, 100 ? Pt ? 0.3916, 200 ? Pt ? 0.3916, 500 ? Pt ? 0.3916, 1000 ? Pt ? 0.3916, 10 ? Cu ? 0.426, 100 ? Ni ? 0.618, 120 ? Ni ? 0.672, 604 ? NiFe ? 0.518
Compatible Thermocouple SensorsThermocouple Type J, K, T, B, E, R, S, N, C
Resistance Input Signal Ranges0-150, 0-1000, 0-3000 ohms
Resolution16 Bits
Input Filters4 Hz, 17 Hz, 62 Hz, 470 Hz
Channel Update Time495, 135, 45, 20 ms
Recommended CableFor TC inputs: shielded, twisted-pair TC extension wire;For RTD, mV, V, or mA inputs: Belden 8761 or equivalent
