Allen Bradley PLC CompactLogix 1769-ASCII
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
TECHNICAL SPECIFICATIONS
| Manufacturer | Industrial Automation / Allen-Bradley |
| Brand | Allen-Bradley |
| Part Number/Catalog No. | 1769-ASCII |
| Product Type: | Specialty module |
| Product Line | CompactLogix |
| Description: | ASCII communication module |
| Module Type | Communication Interface Module |
| Mounting: | Chassis mount; DIN Rail or Panel |
| Software | RSLogix5000 |
| Power Rating: | 425mA @ 5Vdc |
| Shipping Weight | 2 lbs. |
| CompactLogix Power Supply Distance Rating: | 4 |
| Power Dissipation, Max: | 2.13 Watts |
| Shipping Dimensions | 8 x 8 x 5 in. |
| Thermal Dissipation: | 7.3 BTU/hr. |
| Series | A and B |
| Handshaking | RTS/CTS Hardware Handshaking Enabled |
| Temperature Range: | 0-62 deg. C (32 to 140 deg. F) |
| Input Words | 108 |
| Isolation Voltage | 30 Volts Continuous |
| Isolation Voltage | 30 Volts Continuous |
| Backplane Current | 1.4 Amps at 24 Volts |
| Configuration Words: | 31 |
| Power Consumption | 33.6 Watts |
| Number of Inputs: | 2 full duplex (RS-232, RS-422) 2 half duplex (RS-485) |
| Power Dissipation | 7.5 Watts |
| Serial Input Voltage Signal: | 3…25V dc with respect to signal ground (SG) “0â€, Asserted, ON, Space, Active -3…-25V dc with respect to signal ground (SG) “1â€, Disasserted, OFF, Mark, Inactive |
| Recommended cable: | Belden 8761 (Shielded) |
| UPC | 10612598314239 |
| Serial Port status: | TX FIFO overflow, RX FIFO overflow, RX parity error, handshake error, new data flag |
| UNSPSC | 32151705 |
| Transmits Transaction ID: | 0…255 |
