Allen-Bradley 1769-BA

Allen-Bradley 1769-Ba

All products (new, refurbished, and repairs) are covered by the Industrial Automation Co.'s 2-year warranty. Manufacturer’s warranty is void and does not apply. Review our Warranty notice here.


We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.


Payment options

We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.

Credit Terms

We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.

Review our Product Conditions notice here.


$45.00
$45.00
We currently have 5 in stock.

✔ In stock - Ships Today
✔ Eligible for Next Day Delivery

Industrial Automation Co. is NOT an Authorized Rockwell Distributor - we have our own unique inventory and sourcing relationships. Review our Reseller notice here.

  • 1769BA
  • BATTERY ASSEMBLY
  • COMPACTLOGIX
  • BATTERY BACKUP PROGRAM MEMORY AND DATA
  • 3VDC @ 850 MAH
  • LITHIUM

We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.


All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.


Payment options

We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.

Credit Terms

We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.


TECHNICAL SPECIFICATIONS

1769-BA Battery Connection Instructions

Attention: 1769-BA battery is the only battery you can use with the 1769 controllers. The 1747-BA battery is not compatible with 1769 controllers and may cause problems.

Warning: An electrical arc can occur when connecting or disconnecting the battery. In hazardous location installations, this could result in an explosion. Make sure the power is turned off or removed when replacing the battery. Also, confirm the area is nonhazardous before beginning the process.

For more safety information on the handling of lithium batteries, including handling and disposal of leaking batteries, see Guidelines for Handling Lithium Batteries Technical Data, publication AG-5.4.

To connect the battery, follow this procedure:

1. Remove the battery door by sliding it forward.

Important: Do not remove the plastic insulation covering the battery. Insulation is necessary to protect the battery contacts.

2. Insert the battery connector into the black receptacle on the board. The connector is keyed to be installed with the correct polarity.

3. Insert the battery into the door.

4. Slide the battery door back until it clicks into position.
