Description
Industrial Automation Co. is NOT an Authorized Rockwell Distributor - we have our own unique inventory and sourcing relationships.
- 1769IA16
- INPUT MODULE
- COMPACTLOGIX
- DIGITAL
- 16 POINT
- INTERNALLY CONNECTED COMMONS
- 100/120 VAC
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
TECHNICAL SPECIFICATIONS
Manufacturer | Industrial Automation /Allen-Bradley |
Brand | Allen-Bradley |
Part Number/Catalog No. | 1769-IA16 |
Product Type: | Discrete Input Module |
Product Line | CompactLogix |
Module Type | 16 Channel Input Module |
Compatible Controllers: | MicroLogix 1500; 1769 CompactLogix |
Input Type | Analog Input |
Input Voltage: | 100/120 VAC |
Software | RSLogix5000 |
Operating Voltage: | 79 to 132V AC |
Communication Cable | 16 Point |
Input Frequency: | 47 - 63 Hz |
Shipping Weight | 2 pounds |
No. of Inputs: | 16 |
Shipping Dimensions | 8x8x5 inches |
Input delay, On: | 20 ms |
Series | A and B |
Enclosure Type | Open |
Current Draw @ 5.1Vdc: | 115 mA |
Backplane Current | 1.4 Amps at 24 Volts |
Heat Dissipation: | 3.3 W |
Power Consumption | 33.6 Watts |
Off state voltage, max: | 20 VAC |
Power Dissipation | 7.5 Watts |
On state voltage, min: | 79 VAC |
Slot width: | 1 |
Voltage Category | 100 to 102 Volts AC |
Wire size: | (22…14 AWG) solid or (22…16 AWG) |
UPC | 10662468992807 |
Wire type: | Cu-90 °C (194 °F) |
UNSPSC | 32151705 |
Dimension: | 118 x 35 x 87 mm (4.65 x 1.38 x 3.43 in.) Height with mounting tabs 138 mm (5.43 in.)Current Draw @ 5.14Vdc: 425 mA |
