Allen-Bradley 1769-IF4I
We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
Payment options
We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.
Credit Terms
We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.
Description
The Allen-Bradley 1769-IF4I Analog Current/Voltage Isolated Input Module is an integral component of the 1769 CompactLogix 5370 Controller series, featuring four differential analog input channels for precise data conversion. This module supports mixed signal inputs with individual channel isolation, accommodating 0-20 mA, 4-20 mA currents, and ±10 VDC voltages, and offers flexible installation with its compact dimensions and lightweight design. Optimized for use with the MicroLogix 1500 and CompactLogix controllers, the 1769-IF4I ensures reliable operation in industrial environments, featuring a bus interface for communication, removable terminal blocks for ease of wiring, and diagnostic capabilities for detecting configuration errors and signal faults, all while maintaining effective power management with its LED fault indicator.
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
TECHNICAL SPECIFICATIONS
| Manufacturer | Industrial Automation / Allen-Bradley |
| Brand | Allen-Bradley |
| Part Number/Catalog No. | 1769-IF4I |
| Product Type: | Analog Input Module |
| Product Line | CompactLogix |
| Module Type | Isolated Analog Input Module |
| Input Type | Analog Input |
| No. of Inputs: | 4 Individually isolated Differential and single ended inputs |
| Software | RSLogix5000 |
| Power Supply Distance rating: | 8 |
| Communication Cable | 4 Point |
| Input current range: | 0-21 mA |
| Shipping Weight | 2 lbs. |
| Current signal normal ranges: | 0-20mA; 4-20 mA |
| Shipping Dimensions | 8 x 8 x 5 in. |
| Current signal full range: | 0-21 mA; 3.2 - 21 mA. |
| Series | A and B |
| Input / Output voltage range: | 0-10.5VDC |
| Inputs | 4 Isolated Differential |
| Voltage signal normal ranges: | ±10V DC, 0 …10V DC, 0…5V DC, 1…5V DC |
| Voltage signal full range: | ±10.5V DC, -0.5…10.5V DC, -0.5…5.25V DC, 0.5…5.25V DC |
| Replacement Terminal Block | 1769-RTBN18 |
| Converter Type | Sigma-Delta |
| Resolution: | 16 bits (unipolar) 15bits plus sign (bipolar) |
| Wire Type | Copper-90 degrees Celsius |
| Wire Size (Solid) | 22-14 AWG |
| Rated working voltage: | 30VAC; 30VDC |
| UPC | 10781180908634 |
| Channel Diagnostics: | Over- or under-range by bit reporting, process alarms |
| Slot width: | 1 |
| Recommended cable: | Beldenâ„¢ 8761 (shielded) |
| Dimension: | 118 mm (height) x 87 mm (depth) x 35 mm (width) [52.5 mm (width) for 1769-IF8] Height including mounting tabs is 138 mm 4.65 in (height) x 3.43 in (depth) x 1.38 in (width) [2.07 in (width) for 1769-IF8] Height including mounting tabs is 5.43 in |
