Allen-Bradley 1769-IF4XOF2
We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
Payment options
We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.
Credit Terms
We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.
Description
The Allen-Bradley 1769-IF4XOF2 Compact I/O module is a versatile component designed for use with the MicroLogix 1500 and 1769 CompactLogix controllers, offering a cost-effective solution for applications with non-critical precision requirements. This module features four configurable analog input channels compatible with +10V DC or 0 to 20 mA signals and two analog output channels capable of delivering 0 to 10V DC or 0 to 21 mA. With a low-resolution, 8-bit successive approximation ADC and a response speed of 5 milliseconds per channel, the 1769-IF4XOF2 ensures reliable data conversion and communication with a focus on energy efficiency, featuring distinct LED indicators and securing operational safety with c-UL and CE certifications.
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
TECHNICAL SPECIFICATIONS
| Manufacturer | Industrial Automation / Allen-Bradley |
| Brand | Allen-Bradley |
| Part Number/Catalog No. | 1769-IF4XOF2 |
| Product Type: | Analog Input Module |
| Product Line | CompactLogix |
| Module Type | Analog Input/Output Combo Module |
| No. of Inputs: | 4 inputs; Differential or Single Ended |
| Input Type | Analog Input |
| Number of outputs: | 2 Single ended |
| Power Supply Distance rating: | 8 |
| Software | RSLogix5000 |
| Input / Output current range: | 0-21 mA |
| Communication Cable | 4 Point |
| Current signal normal ranges: | 0-20mA; 4-20 mA |
| Shipping Weight | 2 pounds |
| Shipping Dimensions | 8 x 8 x 5 inches |
| Current signal full range: | 0-21 mA; 3.2 - 21 mA. |
| Series | A and B |
| Input / Output voltage range: | 0-10.5VDC |
| Inputs | 4 Isolated Differential |
| Voltage signal normal ranges: | ±10V DC, 0 …10V DC, 0…5V DC, 1…5V DC |
| Voltage signal full range: | ±10.5V DC, -0.5…10.5V DC, -0.5…5.25V DC, 0.5…5.25V DC |
| Converter Type | Delta Sigma |
| Compatible Controllers: | CompactLogix / MicroLogix 1500 |
| Replacement Terminal Block | 1769-RTBN18 |
| Resolution: | 8 bits plus sign (Sign is always positive) |
| Wire Type | Copper-90 degrees Celsius |
| Channel Diagnostics: | Over- or under-range by bit reporting, process alarms |
| Wire Size (Solid) | 22-14 AWG |
| Slot width: | 1 |
| UPC | 10612598286215 |
| Recommended cable: | Beldenâ„¢ 8761 (shielded) |
| UNSPSC | 32151705 |
| Dimension: | 118 mm (height) x 87 mm (depth) x 35 mm (width) [52.5 mm (width) for 1769-IF8] Height including mounting tabs is 138 mm 4.65 in (height) x 3.43 in (depth) x 1.38 in (width) [2.07 in (width) for 1769-IF8] Height including mounting tabs is 5.43 in |
| Programming Software | RSLogix 500; RSLogix 5000; Studio 5000 |
