1769OB16
OUTPUT MODULE
16 POINT
DIGITAL
24 VDC
COMPACTLOGIX
All products are covered by Industrial Automation Co.'s 2-Year Warranty.
Condition
SKU
Price
Warranty
Availability
Quantity
Purchase
Technical specifications for 1769-OB16
Manufacturer
Brand
Allen-Bradley
Part Number/Catalog No.
1769-OB16
Product Family:
Compact I/O
Product Line
CompactLogix
Product Type:
Discrete Output Module
Module Type
DC Output Module
Input Type
Digital Output
No. of Outputs:
16
Power Supply Distance Rating
8
No. of Groups:
1
Communication Cable
16-Point
Voltage Category
24V DC source
Shipping Weight
2 lbs
Shipping Dimensions
8 x 8 x 5 in
Operating Voltage range:
20.4…26.4V DC
Current per point:
0.5 A @ 60 °C (140 °F) 1.0 A @ 30 °C (86 °F)
Power
24 Volts DC
Output delay, On:
0.1 ms
Series
A and B
Output delay, Off:
1.0 ms
Bus Current draw, max:
200 mA
Heat Dissipation:
2.11 W
Wire Size (Solid)
22-14 AWG
Mounting:
DIN rail or panel mount
UPC
10662468992869
Terminal Block:
1769-RTBN18 (1 per kit)
UNSPSC
32151705
Power Supply:
1769-PA2, 1769-PB2, 1769-PA4, 1769-PB4
