Allen-Bradley 1769-OW8
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
Description
The Allen-Bradley 1769-OW8 is a robust relay contact module in the 1769 Compact I/O series, designed for seamless integration with both CompactLogix and MicroLogix 1500 controllers. This versatile module features eight normally open outputs that accommodate a voltage range of 5 to 265 VAC and 5 to 125 VDC. It is capable of handling up to 2.5A continuous current at 240 VAC, 1.0A at 125 VDC, and 2.0A at 24 VDC, making it ideal for industrial and process automation environments. Certified by CE and c-UL, the 1769-OW8 is compatible with power supplies such as the 1769-PA2, 1769-PB2, 1769-PA4, and 1769-PB4, and supports expansion via 1769-ADN DeviceNet or 1769-AENTR Ethernet adapters.
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
TECHNICAL SPECIFICATIONS
| Manufacturer | Industrial Automation / Allen-Bradley |
| Brand | Allen-Bradley |
| Part Number/Catalog No. | 1769-OW8 |
| Product Family: | Compact I/O |
| Product Line | CompactLogix |
| Product Type: | Discrete Output Module |
| Module Type | Relay Output Module |
| Input Type | Relay Output |
| No. of outputs: | Eight (8) |
| Software | RSLogix5000 |
| Power Supply Distance rating: | 8 |
| Communication Cable | 8 Point |
| Programming software: | RSLogix 500, RSLogix 5000; Studio 5000 |
| Shipping Weight | 2 pounds |
| Compatible controllers: | MicroLogix 1500; CompactLogix controllers |
| Shipping Dimensions | 8 x 8 x 5 inches |
| Voltage Category: | AC/DC normally open relay |
| Series | A and B |
| Operating Voltage range: | 5 to 265V ac 5 to 125V dc |
| Signal delay, On: | 10 ms |
| Wire Size (Solid) | 22 to 14 AWG |
| Wire Size (Stranded) | 22 to 16 AWG |
| Bus Current draw, 5.1 V: | 125 mA |
| Wire Type | Copper-90 degrees |
| Wire Type | Copper-90 degrees |
| Bus Current draw, 24 V: | 100 mA |
| Solid Wire Size | 22 to 14 AWG |
| Heat Dissipation: | 2.83 Watts |
| Stranded Wire Size | 22 to 16 AWG |
| Slot width: | 1 |
| UPC | 10662468992890 |
| Mounting: | DIN Rail or Panel Mount |
| Dimensions: | 118 x 35 x 87 mm (4.65 x 1.38 x 3.43 in.) Height with mounting tabs 138 mm (5.43 in.) |
| Power Supply: | 1769-PA2, 1769-PB2, 1769-PA4, 1769-PB4 |
| Wire Size: | (22…14 AWG) solid (22…16 AWG) stranded |
