Allen-Bradley 1769-PA4

Allen-Bradley 1769-Pa4

Allen-Bradley 1769-PA4

$655.50

This product is not available for online purchase. If you would like to receive a quote please use the button below.

Eligible for Next Day Delivery All Parts Come with 24 Month Warranty New, Refurbished and Repairs Available

We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.


All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.


Payment options

We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.

Credit Terms

We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.

Description

Industrial Automation Co. is NOT an Authorized Rockwell Distributor - we have our own unique inventory and sourcing relationships.

  • 1769PA4
  • POWER SUPPLY
  • COMPACTLOGIX
  • 85-265 VAC / 170-265 VAC INPUT
  • 120/220 VAC OUTPUT
  • 18 WATT
  • 25 AMP

Buying Options
Buying Options

All products are covered by Industrial Automation Co.'s 2-Year Warranty.

Condition SKU Price Warranty Availability Quantity Purchase
Surplus Original Box 1769-PA4-FS 2 Year Extended Warranty Call for Availability Call for Availability (877)-727-8757
Quick Repairs and Great Service

Send in your item for a free evaluation and repair quote. Use our RMA form or email a repair request to service@iac.us.com , and we will contact you to assess your situation and offer shipping information.

Quick Search

All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.


TECHNICAL SPECIFICATIONS

Introduction

The Allen-Bradley 1769-PA4 power supply module delivers optimal performance for your CompactLogix systems, equipped to handle a diverse range of industrial automation needs. With switch selectable input voltage and a high power supply distance rating, it integrates seamlessly into your existing automation architecture.

1769-PA4 Technical Specifications

This I/O power supply module operates at 120 Volts AC with an input voltage range of 85…265V AC or 170...265V AC, switch selectable. It's designed to connect up to 8 I/O modules on either side, supporting a maximum of 16 modules. The unit consumes 200 VA @ 120V AC and 240 VA @ 240V AC, with a power dissipation of 8 W @ 60 °C (140 °F).

Installation and Environmental Considerations

For optimal performance, the 1769-PA4 requires an open style environment free from excessive dust and moisture. With dimensions of 118 x 70 x 87 mm and weighing approximately 525 g, its compact design is suitable for tight spaces, ensuring efficient airflow and cooling. The module operates efficiently in an ambient temperature range, further details of which can be found in the user manual.

Elements of Configuration and Connectivity

Complementing the 1769-PA4 module is RSLogix5000 software, facilitating streamlined configuration and programming. It supports copper wire connections (solid or stranded) within specific AWG ranges, showcasing its flexibility in connectivity and installation. For detailed configuration parameters and connectivity options, referencing the manual is recommended.

Enhanced Safety Measures

Beyond its robust design, the 1769-PA4 includes additional safety measures like inrush current protection and recommended fuse types to safeguard against electrical mishaps. It's crucial to adhere to these specifications to maintain safety and performance standards.

Discover the Key Benefits of Allen-Bradley 1769-PA4

Uncover the advantages of integrating the 1769-PA4 into your automation system. Experience unmatched reliability and efficiency in your industrial setups. Order your 1769-PA4 module today and enhance your operational productivity.
