Allen-Bradley 1771-OG
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
Industrial Automation Co. is NOT an Authorized Rockwell Distributor - we have our own unique inventory and sourcing relationships. Review our Reseller notice, here.
The Allen-Bradley 1771-OG PLC 5 TTL Output Module is designed for efficient control applications, featuring 8 sinking/sourcing outputs with keying capability for precise module placement in the 1771 I/O chassis. It operates within a voltage range of 2-5.25V DC for high true signals and -0.2-0.8V DC for low true signals, supporting TTL signal transmission with a required external 5V DC power supply. This module ensures reliability through 1500V AC isolation, draws 168mA from the backplane, and maintains temperature resilience from 0 to 60°C, all while dissipating a maximum of 2.2W of heat energy.
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
TECHNICAL SPECIFICATIONS
| Manufacturer | Rockwell Automation |
| Brand | Allen-Bradley |
| Part Number/Catalog No. | 1771-OG |
| Module Type | Digital DC Output Module |
| Number of Outputs | 8 Ouputs |
| Voltage Category | 5 Volts DC, TTL |
| DC Operating Voltage | 5.0-5.3 Volts |
| Backplane Current | 168 Miliamperes |
| Max Continuous Current Per Output | 0.02 Amperes (Sink) and 0.001 Amperes (Source) |
| Max Continuous Current Per Module | N/A |
| Wiring Arm | 1771-WC |
| Wiring Arm | 1771-WC |
| Coating | Conformal Coat |
| Typical AC Signal Delay (Off) | 45 (+/- 15) ms |
| Typical DC Signal Delay (Off) | 50 ms |
| Wiring Arm | 1771-WH |
| Mounting | Rack Mountable |
| UPC | 10662468205839 |
