Description
Industrial Automation Co. is NOT an Authorized Rockwell Distributor - we have our own unique inventory and sourcing relationships. Review our Reseller notice, here.
The Allen-Bradley 1771-TCM is a robust Temperature Control Module designed for precise thermal management through its eight individually isolated PID loops, compatible with a range of thermocouple types including B, E, J, K, R, S, and T. Operating across diverse temperature scales from -270 to 1800°C depending on the sensor type, this module offers features like thermocouple linearization to IPTS-standard and cold junction compensation. With support for both half and full slot addressing, it seamlessly integrates into 1771 I/O chassis and is compatible with PLC-3, PLC-5, and PLC-5/250 processors. The module is characterized by its high-resolution input, backplane current draw of 1.1A, and surge capacity, along with extensive isolation tested up to 1200V DC, ensuring reliable performance for industrious environments with a working temperature range of 0-60°C.
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
TECHNICAL SPECIFICATIONS
Manufacturer | Rockwell Automation |
Brand | Allen-Bradley |
Part Number/Catalog No. | 1771-TCM |
Module Type | Process Control I/O Module |
Number of Inputs & Outputs | 8 Temperature Inputs (for 8 PID heat/cool loops) |
Input/Output Resolution | 16-Bit Resolution or 15 Bits + Sign Bit |
Analog Inputs | Thermocouple |
Analog Outputs | N/A |
Slots | 1 Slot |
Data Format | Natural Binary 16-Bit Integer |
Backplane Current | 1.5 Amperes |
I/O Connection Hardware | 1771-RTP1 |
Required External Power | None |
Typical AC Signal Delay (Off) | 29 (+/- 8) ms |
Typical DC Signal Delay (Off) | 30 (+/- 7) ms |
Wiring Arm | 1771-WN |
Dimensions | 4.5 x 12.4 x 6.3 in (115 x 317 x 160 mm) |
UPC | 10662468103418 |
