Allen-Bradley 1783-US4T1F
We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
Payment options
We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.
Credit Terms
We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.
Description
The Allen-Bradley 1783-US4T1F is a robust Stratix 2000 Ethernet unmanaged switch, featuring four RJ45 ports and one fiber multi-mode SFP slot, designed for effective network integration. It operates with packet-based thresholds, supporting broadcast storm control at 20 pps for 10 Mbps and 200 pps for 100 Mbps, and delivers an Ethernet data rate of 10-100 Mbps. Housed in an IP20, open-type enclosure suitable for DIN rail mounting, the switch is powered by a 24V, Class 2, SELV power supply, with a current rating of 231 mA and maximum power dissipation of 2.84 W. Designed to function in extreme environments, it has an operating temperature range from -40°F to 158°F and can withstand operating shocks of 15 g and vibrations of 2 g at 10-150 Hz. Additionally, visual monitoring is facilitated by yellow and green LED indicators for power, port speed, and network activity, contributing to efficient system maintenance.
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
TECHNICAL SPECIFICATIONS
Technical specifications for 1783-US4T1F
| Manufacturer | Rockwell Automation |
|---|---|
| Brand | Allen-Bradley |
| Part Number/Catalog No. | 1783-US4T1F |
| Total Ports | 5 |
| RJ45 Ports | 4 Fast Ethernet |
| SFP Ports | 1 Fast Ethernet Mulitmode Preinstalled Fiber SFP Module |
| Max Inrush Current | 1.69 A |
| Power Input | 24V (12?48V DC, 18...30V AC, 50/60 Hz), SELV |
| Max Power Consumption | 3.4 W |
| Nom Current | DC 180 mA; AC 360 mA |
| Max Current | DC 380 mA; AC 750 mA |
| Wire Size: Ground Connection | 2.5 mm2 (14 AWG) Copper Wire Suitable for 187 °F (86 °C) Above Surrounding Ambient Temperature Outside the Enclosure, with Suitable Ring Terminal |
| Wire Size: DC Power Connection | 4.5?5.0 in?lb (0.50?0.56 N?m) |
| Power Terminal Screw Torque | 8.05 in?lb |
| Max Ground Terminal Screw Torque | Open-Style/None |
| Enclosure Type Rating | 4.51 x 3.02 x 1.17 in (114.5 x 76.8 x 29.6 mm) |
| UPC | 884951980167 |
