Allen-Bradley 1783-US5T
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
Industrial Automation Co. is NOT an Authorized Rockwell Distributor - we have our own unique inventory and sourcing relationships. Review our Reseller notice, here.
The Allen-Bradley 1783-US5T is a robust unmanaged Ethernet switch from the Stratix 2000 series, specifically designed for industrial networking applications requiring efficient Ethernet connectivity. Featuring five Fast Ethernet ports with 10/100 Mbps speed, it supports the integration of various automation devices such as PLCs, HMIs, and SCADA systems. This device operates on an external power supply ranging from 12 to 48V DC or 18 to 30V AC, with dimensions of 114.5 mm x 29.6 mm x 68 mm, and is capable of handling harsh environments due to its wide temperature range of -10 to 60 degrees Celsius, relative humidity tolerance of 5-95%, and IP30 rating.
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
TECHNICAL SPECIFICATIONS
Technical specifications for 1783-US5T
| Manufacturer | Rockwell Automation |
|---|---|
| Brand | Allen-Bradley |
| Manufacturer: | |
| Product Family: | Stratix Ethernet Switch |
| Product Type: | Stratix 2000 managed switch |
| Part Number: | 1783-US5T |
| No. of copper ports: | Five (5) copper ports |
| Transmission speed: | 10 / 100 mbps |
| No. of fiber ports: | None |
| Supply voltage range: | 12-48V DC, 18-30V AC, 50/60 Hz |
| Nominal Supply voltage | 24 VAC / VDC |
| Power consumption: | 3.4 Watts |
| Inrush Current: | 1.85 A |
| Part Number/Catalog No. | 1783-US5T |
| Total Ports | 5 |
| RJ45 Ports | 5 Fast Ethernet |
| SFP Ports | 0 |
| Max Inrush Current | 1.85 A |
| Power Input | 24 V (12-48 V DC, 18-30 V AC, 50/60 Hz), SELV |
| Max Power Consumption | 3.4 W |
| Nom Current | DC 180 mA; AC 360 mA |
| Max Current | DC 380 mA; AC 750 mA |
| Wire Size: Ground Connection | 2.5 mm2 (14 AWG) Copper Wire Suitable for 187 degrees F (86 degrees C) Above Surrounding Ambient Temperature Outside the Enclosure, with Suitable Ring Terminal |
| Wire Size: DC Power Connection | 4 x 0.25 mm2 (12 or 24 AWG) Twisted-Pair Copper Wire Suitable for 187 degrees F (86 degrees C) Above Surrounding Ambient Temperature Outside the Enclosure |
| Power Terminal Screw Torque | 4.5x 5.0 in -lb (0.50 x 0.56 N - m) |
| Max Ground Terminal Screw Torque | 8.05 in -lb |
| Enclosure Type Rating | Open-Style/None |
| Dimensions | 4.51 x 3.02 x 1.17 in (114.5 x 76.8 x 29.6 mm) |
| Connector type: | RJ45 |
| UPC | 884951980150 |
| Wire type: | Category 5 (Cat5) based on ISO/IEC 24702; Category 5e (Cat5e) in compliance with TIA 568-B.1 |
| Enclosure type rating | None (open-style) |
| Mounting: | DIN Rail |
| Operating shock: | 15 g |
| Operating Temperature | -10 °C - +60 °C (-4 °F - +140 °F) |
| Temperature, ambient, max | 60 °C (140 °F) |
| Temperature, surrounding air, max | 60 °C (140 °F) |
