Allen-Bradley 1771-VHSC
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
Description
The Allen-Bradley 1771-VHSC is a versatile high-speed counter module designed for precise pulse counting and frequency measurement applications, ideal for motion control and totalizer setups. Featuring four configurable input channels, the module supports multiple modes ‚ rate, encoder, counter, and period/rate ‚ with input frequencies up to 1MHz in single-channel mode, and includes block transfer programming capabilities. Equipped with 12 digital inputs, 8 isolated digital outputs, and compatibility with encoders and pulse generators, it operates efficiently with a 100-microsecond update period and provides robust integration with a variety of high-speed sensors, making it suitable for demanding industrial automation environments.
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
TECHNICAL SPECIFICATIONS
| Typical DC Signal Delay (Off) | 30 (+/- 7) milliseconds |
| Typical AC Signal Delay (Off) | 29 (+/- 8) milliseconds |
| Required External Power | None |
| I/O Connection Hardware | 1771-RTP1 |
| Wiring Arm | 1771-WN |
| Backplane Current | 0.65 Amps |
| Module Update Period | 100 Microseconds |
| Slots | 1 Slot |
| Outputs | 8 Digital Outputs |
| Max Input Frequency | 1 Megahertz (in counter mode) |
| Inputs | 12 Digital Inputs (3 Per Counter) |
| Module Type | High-Speed Counter Module |
| Part Number/Catalog No. | 1771-VHSC |
| Wiring Arm | 1771-WN |
| Dimensions | 4.5 x 12.4 x 6.3 in ches(115 x 317 x 160 millimeters) |
| Manufacturer | Industrial Automation |
| Brand | Allen-Bradley |
