Allen-Bradley 20-HIM-A6
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
Description
Industrial Automation Co. is NOT an Authorized Rockwell Distributor - we have our own unique inventory and sourcing relationships.
- 20HIMA6
- PROGRAMMER
- KEYPAD/DISPLAY
- POWERFLEX 750
- ARCHITECTURE CLASS ENHANCED HIM
- NEMA1
- FOR POWERFLEX
Repair & Service
Quick Repairs and Great Service
Quick Search
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
TECHNICAL SPECIFICATIONS
Technical specifications for 20-HIM-A6
| Brand | Allen-Bradley |
|---|---|
| Series | PowerFlex 700 |
| Manufacturer | Rockwell Automation |
| Description | Human Interface Module (HIM) |
| Protection rating: | NEMA Type 1 |
| Compatible Drives: | PowerFlex 753 drives, PowerFlex 755 drives, PowerFlex 755TL drives, PowerFlex 755TR drives, PowerFlex 755TM common bus inverters, PowerFlex 755TM bus supplies, PowerFlex 70 drives with standard or enhanced control, PowerFlex 700 drives with standard or vector control, PowerFlex 700H drives, PowerFlex 700S drives with Phase I or Phase II control, PowerFlex 700L drives with 700 vector control or 700S control, PowerFlex 700AFE (Active Front End), PowerFlex Digital DC drives, PowerFlex 7000 drives, SMC Flex smart motor controllers and SMC-50 smart motor controllers. |
| Communication Port | One (1) DPI connector port |
| Communication Protocol | Drive Peripheral Interface (DPI) |
| Operating temperature: | 0…50 °C (32…122 °F) |
| Storage temperature: | -40…85 °C (-40…185 °F) |
| Supported languages: | European, English, Asian |
| Operating vibration: | 2.5 g @ 5 Hz…2 kHz |
| Operating shock: | 30 g peak acceleration, 11 (±1) ms pulse width |
| Part Number | 20-HIM-A6 |
| Protocol | Drive Peripheral Interface |
| Data Rates | 125 Kbps or 500 Kbps |
| Consumption | 140 mA at 12V DC supplied by the Host Drive |
| Height | 116.0 mm (4.57 in.) |
| Width | 70.0 mm (2.75 in.) |
| Depth | 16.0 mm (0.63 in.) |
| Weight | 91 g (3.2 oz.) |
| Operating Temperature | 0 to 50 degrees Celsius (32 to 122 degrees Fahrenheit) |
| Storage Temperature | -40 to 85 degrees Celsius (-40 to 185 degrees Fahrenheit) |
| Relative Humidity | 5 to 95% none-condensing |
| UPC | 820919959967 |
Rockwell Disclaimer: The product is used surplus. Industrial Automation Co is not an authorized surplus dealer or affiliate for the Manufacturer of this product. The product may have older date codes or be an older series than that available direct from the factory or authorized dealers. Because Industrial Automation Co is not an authorized distributor of this product, the Original Manufacturer's warranty does not apply. While many Allen-Bradley PLC products will have firmware already installed, Industrial Automation Co makes no representation as to whether a PLC product will or will not have firmware and, if it does have firmware, whether the firmware is the revision level that you need for your application. Industrial Automation Co also makes no representations as to your ability or right to download or otherwise obtain firmware for the product from Rockwell, its distributors, or any other source. Industrial Automation Co also makes no representations as to your right to install any such firmware on the product. Industrial Automation Co will not obtain or supply firmware on your behalf. It is your obligation to comply with the terms of any End-User License Agreement or similar document related to obtaining or installing firmware.
