Allen-Bradley 2093-AC05-MP1
We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
Payment options
We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.
Credit Terms
We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.
Description
Allen-Bradley 2093-AC05-MP1
The Allen-Bradley 2093-AC05-MP1 is a part of the Kinetix 2000 family of multi-axis servo drives. The model is designed to integrate seamlessly with the Kinetix Integrated Motion solution. This servo drive is optimized for applications requiring high performance and flexibility. It operates with a 230V nominal three-phase input.
Technical Description:
The 2093-AC05-MP1 servo drive accepts an AC input voltage ranging from 170 to 264 V with a frequency of 47 to 63 Hz. The nominal input current at AC mains is 11.66 A RMS, with a maximum inrush current of 34.0 A (0-peak).
For DC input, the voltage ranges between 240 to 375 V, supporting a current of 9.76 A. The drive's control power AC input voltage also falls within the 170 to 264 V range for single-phase (230V nominal), with a control power AC input current of 1.25 A and a peak inrush current of 93.0 A.
The bus output voltage of the drive is nominally 325V DC, with a bus overvoltage threshold of 425 V DC and a bus undervoltage limit of 137.5V DC. The model ensures continuous output current to the bus at 9.67 A DC and can handle intermittent output currents up to 19.34 A DC.
The drive 2093-AC05-MP1 features a line loss ride-through capability of 20 ms, ensuring minimal disruption during brief power interruptions. Its efficiency stands at 95%, reflecting its energy-efficient design.
Operational Capabilities:
The 2093-AC05-MP1 is equipped with an internal shunt, providing continuous power of 15 W and peak power of 3000 W. The internal shunt resistor is rated at 50 ?, with shunt activation occurring at 405 V and deactivation at 375V.
The servo drive can deliver a continuous power output to the bus of 3.0 kW, with peak power capabilities reaching 6.0 kW. This makes it suitable for high-demand applications requiring substantial power and rapid response times.
Integration and Compatibility:
This servo drive is designed to integrate with various Allen-Bradley components, such as the ControlLogix and CompactLogix controllers, utilizing the SERCOS interface for real-time communication.
The drive system supports a wide range of compatible servo motors, including the MP-Series (Low Inertia, Food Grade, and Stainless Steel), TL-Series, and Y-Series motors. Additionally, it can interface with integrated linear actuators like the MP-Series MPAI-Axxx (Integrated Actuator).
The model can be installed on a Kinetix 2000 power rail, which simplifies the connection and power distribution between the drive and other system components. The drive supports multiple feedback and communication options, ensuring precise control and monitoring of motor performance.
Environmental Considerations:
The servo drive is designed to operate in demanding industrial conditions. It requires a proper enclosure to meet UL and CE requirements, typically housed in a grounded conductive enclosure offering protection to IP55 standards or higher.
Frequently Asked Questions:
What is the input voltage range for the 2093-AC05-MP1?
The input voltage range for the 2093-AC05-MP1 is 170 to 264 V RMS. This range ensures compatibility with various industrial power systems.
What are the connectivity options available in the 2093-AC05-MP1?
The 2093-AC05-MP1 uses the SERCOS interface for real-time communication. It supports integration with ControlLogix and CompactLogix controllers.
How does the 2093-AC05-MP1 handle regenerative energy?
The 2093-AC05-MP1 features an internal shunt for regenerative energy dissipation. It provides a continuous power of 15 W and a peak power of 3000 W.
Product Specifications Table
| Attribute | Specifications |
|---|---|
| Series | Kinetix 2000 |
| Product Type | Multi-axis Servo Drive |
| Input Voltage Range | 170 to 264V RMS |
| Input Frequency | 47 to 63 Hz |
| Nominal Input Current | 11.66 A RMS |
| Bus Output Voltage | 325V DC |
| Efficiency | 95% |
| Continuous Power Output | 3.0 kW |
| Peak Power Output | 6.0 kW |
| Control Power AC Input Voltage | 170 to 264V RMS single-phase |
