Allen-Bradley 2093-AMP1
We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
Payment options
We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.
Credit Terms
We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.
Description
Allen-Bradley 2093-AMP1
The Allen-Bradley 2093-AMP1 is a high-performance servo drive engineered for precise control in automation applications. It integrates seamlessly with various industrial systems to enhance productivity and accuracy. This servo drive is part of the Kinetix 2000 series designed to handle demanding tasks with exceptional precision.
Technical Description:
The 2093-AMP1 servo drive operates with a nominal input voltage of 325 V DC and boasts a high-efficiency rating of 98 %. It supports a PWM frequency of 8 kHz, which ensures smooth and responsive motor control.
The drive can handle a continuous current of 1.0 A (rms) and a peak current of 3.0 A (rms). For brief high-demand situations, it can sustain a peak current of 4.20 A (0-pk) for up to 3 seconds. The inverter PCB leakage current is maintained at a low level of 1 mA that ensures safe and reliable operation.
The bandwidth capabilities of the drive include a velocity loop at 500 Hz and a current loop at 860 Hz, providing precise and rapid response to control signals. It is equipped with a capacitance of 200 µF and a capacitive energy absorption capacity of 7.5 J.
Performance and Reliability:
The 2093-AMP1 servo drive is designed to operate in a wide range of environmental conditions. It can function within an ambient temperature range of 0 to 50 °C and can be stored safely in temperatures ranging from -40 to 85 °C.
The drive is built to withstand humidity levels from 5% to 95% without condensing, making it suitable for various industrial environments. Its operational altitude is up to 1000 meters, extendable to 3000 meters with derating.
The servo drive meets the IP2X (EN60529) environmental rating that indicates its resilience in less harsh environments. It is compliant with Pollution Degree 2 environments and is suitable for open device usage as per UL508c standards.
The drive is also engineered to resist vibrations of 5...55 Hz at 0.35 mm double amplitude and can endure shocks of 15 g, 11 ms half-sine pulse in three mutually perpendicular directions.
Standard Operating Instructions:
Install the drive in a location that maintains the ambient temperature within 0 to 50 °C. Ensure that the humidity levels do not exceed 95% non-condensing to prevent moisture-related damage. Mount the drive securely to avoid excessive vibration and shock, which could impact its performance and longevity.
Connect the drive to a stable 325 V DC power supply and verify all connections are secure. Regularly inspect the drive for signs of wear or damage and replace components as necessary. Monitor the drives performance, particularly during peak load conditions, to ensure it operates within specified parameters.
Frequently Asked Questions:
What is the nominal input voltage for the Allen-Bradley 2093-AMP1?
The nominal input voltage for the Allen-Bradley 2093-AMP1 is 325V DC. This ensures stable and efficient operation in various industrial applications.
What are the operational temperature and humidity ranges?
The servo drive operates within a temperature range of 0 to 50 °C. It can handle humidity levels from 5% to 95% without condensing, ensuring reliability in diverse environments.
What is the peak current capacity of the 2093-AMP1?
The Allen-Bradley 2093-AMP1 can sustain a peak current of 4.20 A (0-pk). It can maintain this for up to 3 seconds, making it suitable for high-demand situations.
Product Specifications Table
| Attribute | Specifications |
|---|---|
| Series | Kinetix 2000 |
| Product Type | Servo Drive |
| Nominal Input Voltage | 325 V DC |
| Continuous Current | 1.0 A (rms) |
| Peak Current | 4.20 A (0-pk) |
| Efficiency | 98% |
| Operating Temperature Range | 0 to 50 °C |
| Humidity Range | 5% to 95% non-condensing |
| PWM Frequency | 8 kHz |
| Capacitance | 200 µF |
