Description
Allen-Bradley 2094-AM02-S
The Allen-Bradley 2094-AM02-S is an Axis Module designed for high-performance industrial applications. This module is part of the Allen-Bradley Kinetix 6000 series, known for its reliability and efficiency in motion control systems. It is particularly suited for complex automation tasks where precise control of motor functions is essential.
Technical Description:
The 2094-AM02-S Axis Module operates within a 200 VAC class with a nominal drive voltage of 200/230VAC (3 Phase). It has a continuous power output of 3.4 kW, ensuring robust performance for various industrial tasks. The modules capacitance is 780 ?F, with a capacitive energy absorption of 29 J, providing significant energy storage and dissipation capabilities. The voltage class for this module is rated at 200 V.
The nominal input voltage for the 2094-AM02-S is 650 Volts DC, supporting a wide range of operational conditions. It has a continuous current (rms) of 21.2 Amperes and a continuous current (0-peak) of 15.0 Amperes.
The peak current (0-pk) of the model reaches 30.0 Amperes, and the peak current (rms) is 21.2 Amperes. Additionally, the continuous output current (0-pk) is 15.0 Amperes, while the continuous output current (rms) is 10.6 Amperes.
The bandwidth velocity loop of the module is 500 Hertz which ensures quick and accurate response times in motion control. The bandwidth current loop is 1300 Hertz, which helps in maintaining precise current regulation. The power dissipation of the module varies with utilization, with figures such as 34 Watts at 20 % utilization, 45 Watts at 40 %, and up to 84 Watts at 100 % utilization.
Performance and Efficiency:
The 2094-AM02-S Axis Module offers high efficiency, rated at 98%, making it an energy-efficient choice for industrial applications. Its short-circuit current rating is 200,000 A (rms) symmetrical, providing robust protection against electrical faults. The module includes an integrated Safe Torque-off feature that enhances safety during maintenance and emergency situations.
Integration and Compatibility:
This Axis Module is compatible with a variety of Allen-Bradley drives and motors, allowing for seamless integration into existing systems. Its design supports easy configuration and setup, reducing the time required for installation and commissioning.
Standard Installation Instructions:
For proper installation, ensure that the 2094-AM02-S Axis Module is mounted in a well-ventilated area to prevent overheating. Use appropriate mounting hardware to secure the module firmly. Connect the power supply according to the specified voltage and current ratings to avoid damage.
Ensure all electrical connections are tight and secure to maintain reliable operation. Follow all safety guidelines and lockout/tagout procedures during installation and maintenance to prevent accidents. The model must be installed by a highly trained professional in order to get the maximum performance.
Frequently Asked Questions:
What is the continuous power output of the 2094-AM02-S Axis Module?
The 2094-AM02-S has a continuous power output of 3.4 kW. This provides robust performance for various industrial applications.
What are the nominal input voltage requirements for the 2094-AM02-S?
The module requires a nominal input voltage of 650 Volts DC. Ensure the power supply matches this specification to avoid damage.
How efficient is the 2094-AM02-S Axis Module in terms of energy use?
The module has an efficiency rating of 98 %. This makes it an energy-efficient choice for industrial operations.
Product Specifications Table
| Attribute | Specifications |
|---|---|
| Series | Kinetix 6000 |
| Product Type | Axis Module |
| Continuous Power Output | 3.4 kW |
| Nominal Drive Voltage | 200/230VAC (3 Phase) |
| Capacitance | 780 ?F |
| Continuous Current (rms) | 21.2 Amperes |
| Continuous Current (0-peak) | 15.0 Amperes |
| Peak Current (0-peak) | 30.0 Amperes |
| Efficiency | 98 % |
| Bandwidth Velocity Loop | 500 Hertz |
