Description

Allen-Bradley 2094-BC01-M01-M

The Allen-Bradley 2094-BC01-M01-M is an Axis Module designed for advanced motion control applications. Manufactured by Allen-Bradley, this module is part of the Kinetix 6200 series, which is known for its integrated motion solutions. It provides robust performance and flexibility that makes it suitable for various industrial applications.

Technical Description:

The Allen-Bradley 2094-BC01-M01-M operates at a voltage rating of 460 V AC and supports a nominal drive voltage range of 360 – 480 V (3 Phase). It features an integrated axis power module, which simplifies the system architecture by combining multiple functions into a single unit. The module has a wattage rating of 3.9 kW.

One of the key specifications is its max bus capacitance of 4585 microfarads, which enhances its energy storage capability. The module weighs 12.5 lbs (5.67 kg) and has dimensions of 4.9 x 11.9 x 13.2 inches (125 x 302 x 336 mm). This makes it compact and easy to install.

The axis module operates efficiently within a temperature range of 32 – 122 °F (0 – 50 °C), ensuring reliable performance under various environmental conditions. The output current of the module is rated at 9 amperes.

Integrated Motion Control:

The 2094-BC01-M01-M module is designed to provide integrated motion capabilities for motor or drive applications. It can easily transition from Safe Torque Off to Safe Speed Monitor and from the SERCOS interface to the EtherNet/IP networks.

The embedded safety feature eliminates the need for additional panel space and wiring, enhancing system flexibility and reducing setup time. This module is compatible with the Kinetix 6000 servo drive, allowing for easy migration when needed.

Safety Features and Modular Design:

The model's embedded safety features are designed to protect personnel and equipment. The Safe Speed Monitor feature allows maintenance work without completely stopping the machine or monitoring its speed.

Other safety features include Safe Maximum Speed, Safe Maximum Acceleration Monitoring, Safe Direction Monitoring, Zero Speed Monitoring, Enabling Switch Control, and Door Monitoring and Control. These features enhance the overall safety and reliability of the system.

The 2094-BC01-M01-M's modular design provides easy maintenance and greater flexibility. It reduces downtime, energy, and production waste while improving operating efficiency. The embedded advanced safety features help protect personnel by reducing unnecessary start and stop operations.

Standard Operating Precautions:

When operating the Allen-Bradley 2094-BC01-M01-M, it is crucial to adhere to standard operating precautions. Ensure the module is installed in a well-ventilated area to prevent overheating. Regularly inspect the module for any signs of wear or damage.

Always follow the manufacturer's guidelines for installation, operation, and maintenance to ensure optimal performance and longevity of the device. Proper grounding and secure connections are essential to avoid electrical hazards.

Frequently Asked Questions:

What connectivity options does the Allen-Bradley 2094-BC01-M01-M support?

The Allen-Bradley 2094-BC01-M01-M supports EtherNet/IP and SERCOS interface connectivity. This allows seamless integration into various industrial networks.

How much does the Allen-Bradley 2094-BC01-M01-M weigh?

The Allen-Bradley 2094-BC01-M01-M weighs 12.5 lbs (5.67 kg). This makes it manageable for installation and maintenance tasks.

What voltage rating does the 2094-BC01-M01-M support?

The 2094-BC01-M01-M supports a voltage rating of 460V AC. It also supports a nominal drive voltage range of 360-480V (3 Phase).

Product Specifications Table

Attribute	Specifications
Series	Kinetix 6200
Product Type	Axis Module
Wattage	3.9 kW
Voltage Rating	460V AC
Nominal Drive Voltage	360-480V (3 Phase)
Max Bus Capacitance	4585 microfarads
Output Current	9 Amperes
Operating Temperature	32-122°F (0-50°C)
Weight	12.5 lbs (5.67 kg)
Dimensions	4.9 x 11.9 x 13.2 in (125 x 302 x 336 mm)
