Allen-Bradley 2094-BC07-M05

The Allen-Bradley 2094-BC07-M05 is an advanced Integrated Axis Module Converter designed for use with the Kinetix 6000 motion control system. Compact and versatile, it is an essential component for optimizing automation processes in various industrial environments, ensuring superior productivity and minimal downtime

Technical Specifications:

Operating at an input voltage range of 400 to 460 volts. With a current rating of 48 amperes, it is engineered to meet the demanding requirements of high-performance industrial automation applications, ensuring reliable and efficient operation even under heavy load conditions.

Weighing approximately 11.65 kilograms, the Allen-Bradley 2094-BC07-M05 is built for robust performance while maintaining a manageable weight for installation and maintenance purposes.

Its compact form factor, with dimensions measuring 25 cm in width, 20 cm in depth, and 44 cm in height, allows for versatile mounting options within various industrial setups, facilitating easy integration into existing systems.

The Allen-Bradley 2094-BC07-M05 integrates seamlessly with other components in the Kinetix lineup, providing a cohesive and efficient motion control solution. Its advanced features and high-power capacity make it an ideal choice for industries seeking to optimize their automation processes.

Operation and Configuration:

The operation of the Allen-Bradley 2094-BC07-M05 is designed to deliver precise and efficient motion control. Upon installation, the module converts incoming AC power to the necessary DC voltage levels required by servo drives and motors, ensuring consistent performance across various industrial applications.

Configuring the Allen-Bradley 2094-BC07-M05 is a straightforward process. Users can leverage the intuitive interface to set parameters, fine-tune performance, and monitor system status. This seamless integration allows for the precise calibration of motor control functions, ensuring optimal performance tailored to specific application needs.

The configuration also includes safety features that comply with industry standards, providing protection for both the equipment and operators. This flexibility, combined with the modules robust design and advanced functionality, makes the Allen-Bradley 2094-BC07-M05 a versatile and reliable component in any high-performance automation system.

Safety Precautions:

When operating the Allen-Bradley 2094-BC07-M05, it is essential to adhere to stringent safety precautions to ensure the protection of both personnel and equipment. Before commencing any installation or maintenance work, always disconnect the power supply to prevent accidental electrical shocks or short circuits. Verify that the module is properly grounded to mitigate the risk of electric shock and ensure safe operation.

During installation, ensure that the module is securely mounted in an appropriate enclosure that provides adequate ventilation to prevent overheating. Avoid placing the module near sources of excessive heat or moisture, as these conditions can compromise its functionality and safety.

Be aware of the systems operational limits and do not exceed the specified power and current ratings to prevent overloading the module, which could result in catastrophic failure. Following these safety precautions will help maintain a safe working environment and ensure the longevity and reliability of the module.

Frequently Asked Questions:

What is the power output capability of the Allen-Bradley 2094-BC07-M05?

This Allen-Bradley 2094-BC07-M05 is capable of delivering a substantial power output of up to 45 kW. It enables it to handle demanding tasks with ease, making it suitable for environments where high torque and rapid acceleration are critical.

What is the recommended ambient temperature range for operating the Allen-Bradley 2094-BC07-M05?

The recommended ambient temperature range for operating the Allen-Bradley 2094-BC07-M05 is typically between 0°C to 40°C (32°F to 104°F). Operating the module within this temperature range helps ensure optimal performance and longevity.

What is the input and output frequency range of the Allen-Bradley 2094-BC07-M05?

The input frequency range for the Allen-Bradley 2094-BC07-M05 Integrated Axis Module Converter typically spans from 47 Hz to 63 Hz, accommodating standard AC power supplies within this frequency range.

Product Specifications Table

Attribute Specifications Series Kinetix 6000 Horsepower 60 Hp Voltage 360-480 VAC Dimensions 25 x 20 x 44 cm Communication Interface Ethernet/IP Software Compatibility RSLogix 5000 Ambient Temperature Range 0-40°C Control Method V/F control Input/Output Frequency Range 47-63 Hz Mounting Type Panel Mount
