Allen-Bradley 2094-BC07-M05-M

The Allen-Bradley 2094-BC07-M05-M is an Integrated Axis Power Module that embodies reliability, performance, and innovation. With its comprehensive technical specifications and robust design, it serves as a cornerstone in driving efficiency and productivity across industrial automation systems.

Technical Specifications:

With an input power range spanning 360 to 480 volts, Allen-Bradley 2094-BC07-M05-M ensures compatibility with a variety of power supplies, providing a flexible solution for diverse operational environments. Its converter rating of 45 kW and inverter rating of 49 A empower it to manage power flow efficiently, facilitating smooth and precise motion control in machinery and equipment.

Designed to operate within a temperature range of 32 to 122 degrees Fahrenheit (0 to 50 degrees Celsius), the Allen-Bradley 2094-BC07-M05-M exhibits resilience in challenging thermal conditions, ensuring reliable performance even in demanding industrial settings.

Complemented by control input fuses like the FNQ-R-10 (10 A) or FNQ-R-7.5 (7.5 A), this module ensures precise and responsive control over operational parameters, enhancing overall system reliability and performance.

With a compact form factor and a minimum enclosure depth of 302 mm (11.9 inches), the module optimizes space utilization while offering easy integration into existing setups. Its dimensions of 7.7 x 11.9 x 16.7 inches (196 x 302 x 426 mm) that weight contribute to its versatility and ease of deployment across a range of applications.

Installation Instructions:

Confirm that the Allen-Bradley 2094-BC07-M05-M is compatible with the existing automation system and meets the required specifications. Gather all necessary components, including mounting hardware, fuses, and breakers.

Securely mount the Allen-Bradley 2094-BC07-M05-M to the designated surface using the provided mounting hardware. Double-check the mounting orientation to ensure accessibility to input and output terminals as well as ventilation openings.

Before restoring power to the system, conduct a thorough visual inspection of all connections and components to ensure they are secure and free from damage. Perform a continuity test and verify proper wiring polarity to prevent potential electrical faults.

Safety Precautions:

Before performing any work on the power Allen-Bradley 2094-BC07-M05-M, implement lockout/tagout procedures to isolate electrical power sources and prevent accidental energization. Use lockout devices and tags to indicate clearly that maintenance is in progress and to avoid unauthorized re-energization of the system.

Before initiating any electrical work, verify that the power supply to the module has been completely disconnected and that the residual voltage has been safely discharged. Use a voltage tester or multimeter to confirm that no live circuits are present before proceeding with installation or maintenance activities.

Ensure that the installation location provides adequate ventilation and clearance around the power module to prevent overheating and allow for proper airflow. Avoid obstructing ventilation openings or placing the module in confined spaces that could impede cooling and compromise performance.

Frequently Asked Questions:

What is the weight of the Allen-Bradley 2094-BC07-M05-M?

The Allen-Bradley 2094-BC07-M05-M weighs approximately 22.0 pounds (9.98 kilograms), which ensures a robust and stable installation in industrial automation systems.

Which breakers are compatible with the control input section of the Allen-Bradley 2094-BC07-M05-M?

The control input section of the Allen-Bradley 2094-BC07-M05-M is compatible with breakers such as the 1492-SPM2D060 or 1492-SPM1D150, providing flexibility in installation and system integration.

What is the continuous output current to the bus for the Allen-Bradley 2094-BC07-M05-M?

The Allen-Bradley 2094-BC07-M05-M boasts a continuous output current to the bus of 67.7 A, facilitating seamless power distribution within the system. This ensures reliable and efficient operation in demanding industrial applications.

Product Specifications Table

Attribute Specifications Series Kinetix 6000 Horsepower 60.3 Hp Voltage 360 to 480 Volts AC Dimensions 7.7 x 11.9 x 16.7 inches Communication Interface EtherNet/IP, DeviceNet Software Compatibility RSLogix 5000 Ambient Temperature Range 0-50°C (32-122°F) Control Method V/F control Input/Output Frequency Range 47 to 63 Hz Mounting Type Panel Mount
