Allen-Bradley 2094-BM02-M

Allen-Bradley 2094-Bm02-M

Allen-Bradley 2094-BM02-M

Regular price
$1,290.00
Sale price
$1,290.00
We currently have 2 in stock.
Checkmark

In stock - Ships Today

Checkmark

Eligible for Next Day Delivery

Checkmark

Ships From Our North Carolina Warehouse

Eligible for Next Day Delivery All Parts Come with 24 Month Warranty New, Refurbished and Repairs Available


We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.


All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.


Payment options

We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.

Credit Terms

We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.

Description

Allen-Bradley 2094-BM02-M

Allen-Bradley has engineered the 2094-BM02-M to be a versatile and powerful component within the Kinetix 6200 series. It supports a wide range of industrial applications that require precise and reliable motion control. It provides advanced automation solutions with its efficient power management, ease of integration, and robust performance capabilities.

Technical details:

This axis module, operating within the 400-volt voltage class, is engineered for high performance and reliability in various industrial applications. It features a nominal drive voltage range of 360 to 480 Volts AC across three phases, ensuring efficient and stable power delivery.

Designed to handle significant operational demands, the Allen-Bradley 2094-BM02-M dissipates 93 Watts of heat during operation, highlighting its efficiency in energy management. The module can deliver a continuous power output of 6.6 kilowatts, making it suitable for tasks requiring consistent power delivery.

This drive is constructed for practical installation and maintenance. It has a compact footprint, measuring 2.76 x 11.9 x 13.2 inches (70 x 302 x 336 mm). The design allows it to be easily integrated into a cabinet, offering sufficient clearance for air-cooling and maintenance activities.

Operation and Configuration:

Operating the Allen-Bradley 2094-BM02-M involves a series of steps to ensure optimal performance and longevity of the unit. Before powering up the device, it is crucial to verify that all electrical connections comply with the specified wiring standards and that the servo drive is securely mounted in a well-ventilated cabinet.

Upon powering up, the module initializes its systems and performs a self-diagnostic check. This procedure ensures that all internal components are functioning correctly before the drive begins its operational tasks.

Configuring the Allen-Bradley 2094-BM02-M involves several key steps, beginning with the setup of the drive's parameters through a connected interface, typically a computer or a specialized configuration tool.

Maintenance and Troubleshooting:

Regular maintenance should begin with routine visual inspections of the drive and its surrounding environment. Cleaning the drive's exterior and the cabinet interior with a soft brush or compressed air can help maintain optimal thermal performance.

Periodic electrical inspections are also vital. Verify the integrity of all electrical connections, ensuring that there are no signs of wear or corrosion. Lubricate the motor's moving parts as per the manufacturer's recommendations and check for any misalignment or mechanical wear.

Troubleshooting the Allen-Bradley 2094-BM02-M requires a systematic approach to diagnose and rectify issues effectively. If the drive fails to power up, the first step is to check the power supply and ensure that the input voltage is within the specified range. If the drive powers up but does not function correctly, observe the diagnostic LEDs or the error codes displayed on the interface.

If the drive exhibits erratic behaviour or unexpected shutdowns, verify that the configuration settings have not been altered unintentionally. Re-calibrate the drive's parameters and re-tune the control loops if necessary.

Frequently Asked Questions:

What is the operating temperature range of the Allen-Bradley 2094-BM02-M?

The operating temperature range for the Allen-Bradley 2094-BM02-M is between 32 to 122 degrees Fahrenheit (0 to 50 degrees Celsius). This wide temperature range ensures reliable performance in various environmental conditions.

What is the output current rating of the 2094-BM02-M?

The 2094-BM02-M provides an output current of 15 Amperes, ensuring robust performance under continuous load. This current rating allows the drive to efficiently power connected motors and other components within industrial automation systems, making it suitable for various demanding applications.

What is the weight of the Allen-Bradley 2094-BM02-M?

The Allen-Bradley 2094-BM02-M weighs 7.0 pounds (3.18 kilograms). This weight specification is important for installation planning and ensuring proper load distribution within industrial automation systems.

Product Specifications Table

Attribute Specifications Series Kinetix 6200 Horsepower 8.8 Hp Voltage 360-480 VAC Dimensions 2.76 x 11.9 x 13.2 inches Communication Interface Ethernet/IP Software Compatibility RSLogix 5000 Ambient Temperature Range 0-50°C (32-122°F) Control Method V/F control Input/Output Frequency Range 0-500 Hz Mounting Type Panel Mount
Buying Options
Buying Options

All products are covered by Industrial Automation Co.'s 2-Year Warranty.

Condition SKU Price Warranty Availability Quantity Purchase
IAC Certified Refurbished 2094-BM02-M-R $1,290.00 USD 2 Year Extended Warranty 2 In Stock in the U.S.A!
Quick Repairs and Great Service

Send in your item for a free evaluation and repair quote. Use our RMA form or email a repair request to service@iac.us.com , and we will contact you to assess your situation and offer shipping information.
