Allen-Bradley 2097-V33PR5
We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
Payment options
We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.
Credit Terms
We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.
Description
Allen-Bradley 2097-V33PR5
The Allen-Bradley 2097-V33PR5 is a Kinetix 300 Ethernet/IP Indexing Servo Drive designed for meticulous motion control applications. Known for its robust performance, the 2097-V33PR5 supports precise positioning and speed regulation, making it ideal for tasks requiring high precision and repeatability.
Technical Features:
The Allen-Bradley 2097-V33PR5 servo drive is designed to deliver a persistent power output of 2.00 kW. This power guarantees that the drive can maintain a steady power supply for prolonged operations, essential for applications that demand consistent performance.
Besides its robust continuous power output, the 2097-V33PR5 servo drive also features a peak output current of 33.9 A (0-peak). This high peak current capacity allows the drive to handle short bursts of power, often necessary during rapid acceleration or deceleration phases in motion control applications.
The Allen-Bradley 2097-V33PR5 servo drive puffs impressive electrical specifications tailored for high-performance industrial applications. One of the key specifications is its peak output current, measured at 24.0 A RMS.
In terms of constant output current, the Allen-Bradley 2097-V33PR5 offers 11.3 A (0-peak). This specification indicates the drives ability to consistently deliver a steady current to the motor, ensuring smooth and uninterrupted operation.
The continuous output current in RMS terms is 8.0 A. RMS (Root Mean Square) values accurately represent the drives capacity to deliver continuous power under normal operating conditions.
The Allen-Bradley 2097-V33PR5 drive is designed with compact proportions, making it suitable for various industrial environments where space is a consideration. The drive measures 9.37 inches in height, 7.29 inches in width, and 3.72 inches in depth (238 x 185 x 94.0 mm).
Operating Temperature Range:
The Allen-Bradley 2097-V33PR5 is designed to perform efficiently within a distinct range of ambient situations, providing optimal performance and longevity. The operational temperature range for this servo drive is from 32°F to 104°F (0°C to 40°C). This temperature range indicates that the drive can function reliably in a variety of environments, from cooler industrial settings to warmer conditions.
Advanced Control Features of the Allen-Bradley 2097-V33PR5:
The 2097-V33PR5 servo drive is engineered with a versatile control architecture capable of executing five different indexing types and supporting S-curve and trapezoidal motion profiles.
The 2097-V33PR5 offers 32 index capabilities for precise position-control applications, making it highly adaptable for various motion control tasks. This servo drive enables multiple control methods, including indexing, PTO (Pulse Train Output), analog, and Ethernet/IP commanded control of actuators and servo motors.
Additional control features include master gearing, analog input control, and step and direction control, providing a comprehensive solution for complex motion requirements.
Frequently Asked Questions:
What is the power dissipation of the Allen-Bradley 2097-V33PR5 servo drive, and why is it important?
The 2097-V33PR5 servo drive has a power dissipation of 67 watts. Managing power dissipation is crucial because excessive heat can lead to overheating, potentially damaging the internal components and reducing the overall efficiency.
What torque value does the 2097-V33PR5 provide?
The Allen-Bradley 2097-V33PR5 provides a torque value of 4.5 lb*in (0.5 Nm). A torque value of 4.5 lb*in indicates that the drive can exert moderate rotational force, making it suited for applications requiring accurate and steady movements.
Does the 2097-V33PR5 come with an integrated AC line filter, and what are the implications of this?
No, the 2097-V33PR5 does not have an integrated AC line filter. The absence of an integrated AC line filter means that users may need to install an external line filter to achieve the desired level of EMI suppression and power quality.
Product Specifications Table
| Attribute | Specifications |
|---|---|
| Series | Kinetix 300 |
| Horsepower | Approximately 2.68 HP (2.0 kW) |
| Voltage | 120 /240 Volts (One Phase); 240 Volts (Three Phase) |
| Dimensions | 9.37 x 7.29 x 3.72 in (238 x 185 x 94.0 mm) |
| Communication Interface | Ethernet/IP |
| Software Compatibility | RSLogix 5000 |
| Ambient Temperature Range | 32° - 104° F (0° - 40° C) |
| Control Method | Safe Torque-Off (STO) |
| Input/Output Frequency Range | 48 - 62 Hz |
| Mounting Type | Panel mount |
