Allen-Bradley 2097-V34PR3
We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
Payment options
We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.
Credit Terms
We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.
Description
Allen-Bradley 2097-V34PR3
The Allen-Bradley 2097-V34PR3 belongs to the Kinetix 300 servo drives designed for cost-effective single-axis motion control. This drive seamlessly incorporates into EtherNet/IP networks, streamlining wiring and simplifying integration into enormous automation systems. The 2097-V34PR3 excels in applications requiring meticulous, autonomous, and non-coordinated indexing moves, making it suitable for miscellaneous industrial settings.
Technical Features:
The Allen-Bradley 2097-V34PR3 drive is designed to deliver a steady power output of 1.00 kW, making it appropriate for applications that demand uniform performance and reliability. Regarding peak output current, the 2097-V34PR3 can achieve up to 6.0 A (RMS), which is essential for applications that experience momentary high load demands.
The Allen-Bradley 2097-V34PR3 servo drive features a control power backup input current with a maximum inrush of 30 A. This specification indicates the peak current required by the drive when it is first powered on or when switching on, confirming that the drive can handle initial power demands without causing disruptions or deterioration to the system.
The nominal control power backup input current is 500 mA. This value represents the steady-state current needed to maintain the control circuitrys operation during normal conditions.
The control power backup input voltage range 2097-V34PR3 is specified between 20 to 26V DC. This range provides flexibility in power supply selection, ensuring compatibility with various industrial power systems and enhancing the drives adaptability to different installation environments.
Additionally, the maximum inrush current for the drive is rated at 4.5 A. This specification is crucial for understanding the drives initial power surge when powered on, helping properly design and protect the electrical system to accommodate this transient condition.
The Allen-Bradley 2097-V34PR3 servo drive is engineered with a nominal main AC input current of 2.7 A (RMS). The drive also supports an input frequency range of 48 to 62 Hz, providing flexibility and compatibility with standard and slightly varied industrial power supplies.
Ambient Conditions:
The 2097-V34PR3 functions efficiently between 0 and 40 °C. This range guarantees the drive can function reliably in various environmental conditions without compromising performance. Additionally, the drive can endure a relative humidity level between 5% and 95%.
The mounting surface must remain free from significant vibrations and shocks for installation. The drive is rated to resist vibrations from 5 to 2000 Hz at a peak of 2.5 g, with a maximum displacement of 0.015 mm. Furthermore, it can survive shocks of up to 15 g for 11 milliseconds in half-sine pulses.
Enhanced Safety with Built-in Safe Torque-Off:
The Allen-Bradley 2097-V34PR3 servo drive includes a built-in Safe Torque-Off (STO) function that meets ISO 13849-1 PLD/SIL2 safety standards. This state-of-the-art safety attribute protects the operational environment and personnel by ensuring the drive or motor does not automatically restart following a safety circuit trip.
Frequently Asked Questions:
What is the input voltage range for the Allen-Bradley 2097-V34PR3?
The Allen-Bradley 2097-V34PR3 servo drive operates with an input voltage range of 320-528V RMS three-phase, with a nominal voltage of 480V.
How much power does the 2097-V34PR3 servo drive dissipate, and what implications does this have for system design?
The 2097-V34PR3 servo drive dissipates 39 watts of power. This relatively low power dissipation is advantageous for system design as it minimizes the heat generated by the drive, reducing the need for extensive cooling solutions.
What is the weight of the Allen-Bradley 2097-V34PR3, and how does this affect its installation and use?
The Allen-Bradley 2097-V34PR3 servo drive weighs 3.3 lbs (1.5 kg). This lightweight design fosters easier handling and installation, allowing for more flexibility in mounting options and locations.
Product Specifications Table
| Attribute | Specifications |
|---|---|
| Series | Kinetix 300 |
| Horsepower | 1 kW (1.34 hp) |
| Voltage | 320-528V AC, 480V nominal |
| Dimensions | 9.37 x 7.29 x 2.70 in (238 x 185 x 69.0 mm) |
| Communication Interface | EtherNet/IP |
| Weight | 3.3 lbs (1.5 kg) |
| Ambient Temperature Range | 0° to 40° C (32° to 104° F) |
| Relative Humidity | 5-95% non-condensing |
| Input/Output Frequency Range | 48-62 Hz |
| Certification | ISO 13849-1 PLD/SIL2 |
