Allen-Bradley 2098-DSD-HV050X

Allen-Bradley 2098-DSD-HV050X
Allen-Bradley 2098-DSD-HV050X

Allen-Bradley 2098-DSD-HV050X

$0.00

This product is not available for online purchase. If you would like to receive a quote please use the button below.

Request a Price Quote
Eligible for Next Day Delivery All Parts Come with 24 Month Warranty New, Refurbished and Repairs Available

We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.


All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.


Payment options

We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.

Credit Terms

We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.

Description

The Allen-Bradley 2098-DSD-HV050X is an Ultra 3000i Digital Servo Indexing Drive designed for high-performance motion applications. Featuring user-configurable I/O channels, this drive includes a 14-bit resolution analog command input with a ±10V range and a 10-bit ILIMIT input ranging from 0 to 10V, complemented by an 8-bit analog output capable of ±10VDC. It operates on a 230-480V AC three-phase input with a 47-63 Hz frequency, delivering continuous output power of up to 5.0 kW at 460VAC. The drive is compatible with various encoder feedback options, including incremental, sine/cosine, and absolute, supporting maximum input frequencies up to 2.5 MHz. Designed for robust environments, the 2098-DSD-HV050X endures operating temperatures between 0 to 55°C, offers a relative humidity tolerance of 5-95%, and manages shock and vibration impacts up to 15g and 2.5g, respectively.


Buying Options
Buying Options

All products are covered by Industrial Automation Co.'s 2-Year Warranty.

Condition SKU Price Warranty Availability Quantity Purchase
Surplus Original Box 2098-DSD-HV050X 2 Year Extended Warranty Call for Availability Call for Availability (877)-727-8757
Quick Repairs and Great Service

Send in your item for a free evaluation and repair quote. Use our RMA form or email a repair request to service@iac.us.com , and we will contact you to assess your situation and offer shipping information.

Quick Search

All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.


TECHNICAL SPECIFICATIONS

Technical specifications for 2098-DSD-HV050X

Shunt On 800V dc
Bus Overvoltage 810V dc
Bus Capacitance 470 ?F
Input Voltage (AC) 230...480V rms Three-phase)
Input Frequency (AC) 47-63 Hz
Nominal Input Current (AC) 7 Amp, rms
Output Current (Continuous) 11 Amps (0-peak)
Output Current (Intermittent) 22 Amps (0-peak)
Part Number/Catalog No. 2098-DSD-HV050X
Features Indexing
Internal Shunt Resistance 120 ?
Brand Allen-Bradley
Manufacturer Rockwell Automation
Series Ultra 3000 Drives with Indexing
Communication Port One (1) Serial Port
Data Rate 1200, 2400, 4800, 9600, 19200, and 38400 baud
Shunt Off 750V dc
Status Indicator Seven Segment Status LED
Series Ultra 3000 Drives
Auxiliary Power Supply Yes
Dimensions 750 Volts dc
Weight 9.54 x 14.2 x 5.46 in (242.2 x 360.7 x 138.7 mm)
