Allen-Bradley 2098-DSD-HV100

Allen-Bradley 2098-DSD-HV100

Allen-Bradley 2098-DSD-HV100

$0.00

This product is not available for online purchase. If you would like to receive a quote please use the button below.

Request a Price Quote
Eligible for Next Day Delivery All Parts Come with 24 Month Warranty New, Refurbished and Repairs Available

We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.


All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.


Payment options

We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.

Credit Terms

We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.

Description

The Allen-Bradley 2098-DSD-HV100, from the Ultra3000 series, is a versatile servo drive engineered for optimal performance with Kinetix and other third-party servo motors. Designed for a 3-phase power supply, it operates between 230 and 480 VAC and supports a frequency range of 47-63 Hz. It offers a continuous output current of 23 Amperes and an intermittent output current of up to 46 Amperes, with power capabilities reaching up to 10 kW at 460 Volts AC. This drive is compact, with dimensions of 9.54 x 14.2 x 5.97 inches (242.2 x 360.7 x 151.6 mm), and includes D-shell connectors for high-density signal connections to minimize errors. Equipped with RS-485 connectivity, the 2098-DSD-HV100 supports multi-drive installations and features internal shunt resistance to manage voltage levels efficiently. It is ideally suited for diverse applications, ensuring robust performance and reliability in sensitive environments.


Buying Options
Buying Options

All products are covered by Industrial Automation Co.'s 2-Year Warranty.

Condition SKU Price Warranty Availability Quantity Purchase
Surplus Original Box 2098-DSD-HV100 2 Year Extended Warranty Call for Availability Call for Availability (877)-727-8757
Quick Repairs and Great Service

Send in your item for a free evaluation and repair quote. Use our RMA form or email a repair request to service@iac.us.com , and we will contact you to assess your situation and offer shipping information.

Quick Search

All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.


TECHNICAL SPECIFICATIONS

Technical specifications for 2098-DSD-HV100

Manufacturer Rockwell Automation
Shunt On 800 V dc
Bus Overvoltage 810 V dc
Bus Capacitance 705 ?F
Input Voltage (AC) 120 - 240 Voltage rms, 1-Phase
Input Frequency (AC) 47-63 Hz
Output Current (Continuous) 46 Amps (0-peak)
Output Current (Intermittent) 23 Amps (0-peak)
Part Number/Catalog No. 2098-DSD-HV100
Brand Allen-Bradley
Continuous output power @ 230 VAC 5.0 kW
Continuous output power @ 480 VAC 10.0 kW
Shunt Off 750 V dc
SERCOS No
I/O Channels Eight (8) Discrete input signals; Four (4) discrete output; One (1) Normally Open (N.O.) relay contact output; One (1) Analog current limit input; One (1) Programmable analog output.
Series Ultra 3000 Drives
Auxiliary Power Supply Yes
Nominal Input Current (AC) 14 Amps Root Means Square
Dimensions 750 Volts dc
Features Standard
Internal Shunt Resistance 40 Ohms
