Allen-Bradley 2098-DSD-HV150-SE
The Allen-Bradley 2098-DSD-HV150-SE, from the Ultra 3000 series, excels in multi-axis motion control. Its SERCOS interface ensures high-speed, meticulous communication and synchronization with other automation components.
Technical Features:
The Allen-Bradley 2098-DSD-HV150-SE boasts specialized specifications that foster its performance and versatility in industrial automation. A key trait is its shunt voltage rating, which is capable of handling up to 750V DC. This allows the drive to manage high-energy surges effectively, ensuring stability and safeguarding the system from possible overvoltage damage.
Another crucial aspect is the drives bus capacitance, which is rated at 940 microfarads (µF). This large capacitance value helps to smooth out voltage fluctuations and maintain a consistent power supply to the servo motors.
In terms of communication capabilities, the drive offers a versatile data rate for serial communications, supporting speeds of 1200, 2400, 4800, 9600, 19200, and 38400 baud. For SERCOS interface communications, the drive supports data rates of 4 and 8 Mbit.
Furthermore, the Allen-Bradley 2098-DSD-HV150-SE includes one serial communication port, enhancing its connectivity options. This port allows for straightforward integration with other devices and systems, facilitating communication and control in complex automation environments.
The 2098-DSD-HV150-SE is engineered to deliver substantial power output, making it suitable for demanding industrial applications. The drives current output capabilities are a testament to its robust design and efficiency. It provides an intermittent output current of 68 amps peak.
In addition to its intermittent capabilities, the drive also offers a steady output current of 34 amps peak. This persistent current rating guarantees that the drive can sustain a steady flow of power over extended periods, ensuring reliable and consistent performance in continuous operation scenarios.
The Allen-Bradley 2098-DSD-HV150-SE drive also features an auxiliary power supply, enhancing its flexibility and utility in diverse industrial applications.
Enhanced Communication Capabilities:
The Allen-Bradley 2098-DSD-HV150-SE drive uses the SERCOS interface for smooth communication with controllers equipped with the 1756 SERCOS module and SoftLogix systems with a SERCOS interface in the PCI slot of any workstation. This setup ensures efficient, synchronized control and high reliability in complex industrial applications.
Installation Instructions:
To install the Allen-Bradley 2098-DSD-HV150-SE, first read the user manual for safety precautions and instructions. Gather the necessary tools and verify that all components are intact. Begin by mounting the drive on a flat, vertical surface with adequate ventilation, ensuring easy access to the front panel and connectors.
Connect the main power supply and the auxiliary power supply to their respective terminals, ensuring all connections are tight and properly grounded. Next, attach the motor leads to the drives output terminals, confirming compatibility with the drives specifications. Connect the SERCOS interface or serial communication cable to the designated port.
Frequently Asked Questions:
How to interpret the status indicators on 2098-DSD-HV150-SE?
The status indicators, shown on a seven-segment LED display, provide diagnostic information. Each code represents specific operational statuses or faults. Consult the user manual for detailed explanations of each code and corrective actions.
What is the input frequency range for the Allen-Bradley 2098-DSD-HV150-SE drive, and why is it important?
The input frequency range for the 2098-DSD-HV150-SE is 47-63 Hz. Operating within this range is essential for optimal performance and to prevent potential damage.
What to do if 2098-DSD-HV150-SE experiences a bus overvoltage fault?
If the 2098-DSD-HV150-SE servo drive shows a bus overvoltage fault (exceeding 810V DC), check the input supply voltage, inspect for power surges or fluctuations, and verify the braking resistors functionality.
Product Specifications Table
| Attribute | Specifications |
|---|---|
| Series | Ultra 3000 |
| Peak Output Current | 68A |
| Voltage | 230/460 V AC |
| Dimensions | 6.0? x 10.0? x 14.5? (15.2 cm x 25.4 cm x 36.8 cm) |
| Communication Interface | SERCOS |
| Power Rating | 7.5 kW at 230V AC, 15 kW at 460V AC |
| Ambient Temperature Range | -40 to 70 degrees Celsius |
| Control Method | Digital Servo Control |
| Input/Output Frequency Range | 47-63 Hz (Input) |
| Mounting Type | Panel Mount |
