Allen-Bradley 2098-IPD-020

Allen-Bradley 2098-Ipd-020 Industrial Automation & Control

Allen-Bradley 2098-IPD-020

$2,190.00
$2,190.00
We currently have 1 in stock.
Checkmark

In stock - Ships Today

Checkmark

Eligible for Next Day Delivery

Checkmark

Ships From Our North Carolina Warehouse

Eligible for Next Day Delivery All Parts Come with 24 Month Warranty New, Refurbished and Repairs Available

We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.


All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.


Payment options

We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.

Credit Terms

We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.

Description

The Allen-Bradley 2098-IPD-020 Ultra 5000 Intelligent Positioning Drive is expertly designed for driving servo motors with high precision. Operating on a single-phase AC input voltage of 100 to 240 Vrms and a frequency range of 47 to 63 Hz, this drive offers significant output with up to 2 kW of power at 230 VAC input and a peak current capacity of 30A, ensuring robust performance. It accommodates various industrial conditions with a rugged design that requires installation in an IEC60529-compliant enclosure to protect against shocks and contaminants, while maintaining an ambient temperature below 55°C. Featuring versatile I/O connections, the drive includes a pluggable spring clamp 28-pin CN1A connector for digital I/O and a 14-pin CN1B connector for auxiliary encoder and analog I/O, complemented by eight digital outputs and a single relay output for flexible system integration.


Buying Options
Buying Options

All products are covered by Industrial Automation Co.'s 2-Year Warranty.

Condition SKU Price Warranty Availability Quantity Purchase
IAC Certified Refurbished 2098-IPD-020-R $2,190.00 USD 2 Year Extended Warranty 1 In Stock in the U.S.A!
Quick Repairs and Great Service

Send in your item for a free evaluation and repair quote. Use our RMA form or email a repair request to service@iac.us.com , and we will contact you to assess your situation and offer shipping information.

Quick Search

All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.


TECHNICAL SPECIFICATIONS

Technical specifications for 2098-IPD-020

Manufacturer Rockwell Automation
Part Number/Catalog No. 2098-IPD-020
Brand Allen-Bradley
Series Ultra5000 Intelligent Positioning Drives
Output Peak Current 30A (0-peak)
Continuous Output Current 10A (0-peak)
Continuous Power Output, 115V ac input 1 kW
Continuous Power Output, 230V ac input 2 kW
AC input Voltage 100-240Vrms, 1-Phase
AC Input Frequency 47 - 63 Hz
AC Input Current 18A
Maximum inrush (230V ac input) 100A (0-peak)
Energy Absorption Capability, 115VAC 125 Joules
Energy Absorption Capability, 230VAC 51 Joules
Series Ultra 5000 Drives
Output Current (Intermittent) N/A
Output Current (Continuous) 10 Amps (0-peak)
Auxiliary Power Supply No
Nominal Input Current (AC) 18 Amps Root Means Square
Input Frequency (AC) 47-63 Hz
Input Voltage (AC) 100-240 Voltage Root Means Square (Single Phase)
Internal Shunt Resistance N/A
Bus Overvoltage N/A
Shunt On N/A
Dimensions N/A
Weight 5.50 x 5.69 x 8.08 in (139.70 x 144.53 x 205.23 mm)
Features Standard
Bus Capacitance N/A
